4KF4

Crystal Structure of sfCherry


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.99 Å
  • R-Value Free: 0.265
  • R-Value Work: 0.222
  • R-Value Observed: 0.223

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Split green fluorescent protein as a modular binding partner for protein crystallization.

Nguyen, H.B.Hung, L.W.Yeates, T.O.Terwilliger, T.C.Waldo, G.S.

(2013) Acta Crystallogr D Biol Crystallogr 69: 2513-2523

  • DOI: 10.1107/S0907444913024608
  • Primary Citation of Related Structures:
    4KF4, 4KF5

  • PubMed Abstract:
  • A modular strategy for protein crystallization using split green fluorescent protein (GFP) as a crystallization partner is demonstrated. Insertion of a hairpin containing GFP β-strands 10 and 11 into a surface loop of a target protein provides two chain crossings between the target and the reconstituted GFP compared with the single connection afforded by terminal GFP fusions ...

    A modular strategy for protein crystallization using split green fluorescent protein (GFP) as a crystallization partner is demonstrated. Insertion of a hairpin containing GFP β-strands 10 and 11 into a surface loop of a target protein provides two chain crossings between the target and the reconstituted GFP compared with the single connection afforded by terminal GFP fusions. This strategy was tested by inserting this hairpin into a loop of another fluorescent protein, sfCherry. The crystal structure of the sfCherry-GFP(10-11) hairpin in complex with GFP(1-9) was determined at a resolution of 2.6 Å. Analysis of the complex shows that the reconstituted GFP is attached to the target protein (sfCherry) in a structurally ordered way. This work opens the way to rapidly creating crystallization variants by reconstituting a target protein bearing the GFP(10-11) hairpin with a variety of GFP(1-9) mutants engineered for favorable crystallization.


    Organizational Affiliation

    Bioscience Division, Los Alamos National Laboratory, MS M888, Los Alamos, NM 87545, USA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
fluorescent protein sfCherry
A, B, C, D, E, F, G, H
A, B, C, D, E, F, G, H
223synthetic constructMutation(s): 0
UniProt
Find proteins for Q9U6Y8 (Discosoma sp.)
Explore Q9U6Y8
Go to UniProtKB:  Q9U6Y8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9U6Y8
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
CH6
Query on CH6
A, B, C, D, E, F, G, H
A, B, C, D, E, F, G, H
L-PEPTIDE LINKINGC16 H19 N3 O4 SMET, TYR, GLY
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.99 Å
  • R-Value Free: 0.265
  • R-Value Work: 0.222
  • R-Value Observed: 0.223
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 85.105α = 90
b = 96.294β = 104.56
c = 105.957γ = 90
Software Package:
Software NamePurpose
ADSCdata collection
PHASESphasing
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2013-12-18
    Type: Initial release
