4JT0

Yeast 20S proteasome in complex with the dimerized linear mimetic of TMC-95A - yCP:4a

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.1 Å
  • R-Value Free: 0.223
  • R-Value Work: 0.216

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history.

Literature

Dimerized Linear Mimics of a Natural Cyclopeptide (TMC-95A) Are Potent Noncovalent Inhibitors of the Eukaryotic 20S Proteasome

Desvergne, A., Genin, E., Marechal, X., Gallastegui, N., Dufau, L., Richy, N., Groll, M., Vidal, J., Reboud-Ravaux, M.

(2013) J.Med.Chem. --: --

  • DOI: 10.1021/jm4002007
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    • Noncovalent proteasome inhibitors introduce an alternative mechanism of inhibition to that of covalent inhibitors used in cancer therapy. Starting from a noncovalent linear mimic of TMC-95A, a series of dimerized inhibitors using polyaminohexanoic ac ...

    Noncovalent proteasome inhibitors introduce an alternative mechanism of inhibition to that of covalent inhibitors used in cancer therapy. Starting from a noncovalent linear mimic of TMC-95A, a series of dimerized inhibitors using polyaminohexanoic acid spacers has been designed and optimized to target simultaneously two of the six active sites of the eukaryotic 20S proteasome. The homodimerized compounds actively inhibited chymotrypsin-like (Ki = 6-11 nM) and trypsin-like activities, whereas postacid activity was poorly modified. The noncovalent binding mode was ascertained by X-ray crystallography of the inhibitors complexed with the yeast 20S proteasome. The inhibition of proteasomal activities in human cells was evaluated. The use of the multivalency inhibitor concept has produced highly efficient and selective noncovalent compounds (no inhibition of calpain and cathepsin) that have potential therapeutic advantages compared to covalent binders such as bortezomib and carfilzomib.

    Organizational Affiliation:

    Enzymologie Moléculaire et Fonctionnelle, UR4, University Paris 6, Pierre et Marie Curie, UPMC-Sorbonne Universités, Case 256, 7 Quai Saint Bernard, 75252 Paris Cedex 05, France.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Proteasome subunit alpha type-2
A, O
250Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: PRE8 (PRS4)
EC: 3.4.25.1
Find proteins for P23639 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P23639
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Proteasome subunit alpha type-3
B, P
258Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: PRE9 (PRS5)
EC: 3.4.25.1
Find proteins for P23638 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P23638
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
Proteasome subunit alpha type-4
C, Q
254Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: PRE6
EC: 3.4.25.1
Find proteins for P40303 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P40303
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
Proteasome subunit alpha type-5
D, R
260Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: PUP2 (DOA5)
EC: 3.4.25.1
Find proteins for P32379 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P32379
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetails
Proteasome subunit alpha type-6
E, S
234Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: PRE5
EC: 3.4.25.1
Find proteins for P40302 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P40302
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetails
Probable proteasome subunit alpha type-7
F, T
288Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: PRE10 (PRC1, PRS1)
EC: 3.4.25.1
Find proteins for P21242 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P21242
Entity ID: 7
MoleculeChainsSequence LengthOrganismDetails
Proteasome subunit alpha type-1
G, U
252Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: SCL1 (PRC2, PRS2)
EC: 3.4.25.1
Find proteins for P21243 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P21243
Entity ID: 8
MoleculeChainsSequence LengthOrganismDetails
Proteasome subunit beta type-2
H, V
232Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: PUP1
EC: 3.4.25.1
Find proteins for P25043 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P25043
Entity ID: 9
MoleculeChainsSequence LengthOrganismDetails
Proteasome subunit beta type-3
I, W
205Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: PUP3
EC: 3.4.25.1
Find proteins for P25451 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P25451
Entity ID: 10
MoleculeChainsSequence LengthOrganismDetails
Proteasome subunit beta type-4
J, X
198Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: PRE1
EC: 3.4.25.1
Find proteins for P22141 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P22141
Entity ID: 11
MoleculeChainsSequence LengthOrganismDetails
Proteasome subunit beta type-5
K, Y
212Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: PRE2 (DOA3, PRG1)
EC: 3.4.25.1
Find proteins for P30656 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P30656
Entity ID: 12
MoleculeChainsSequence LengthOrganismDetails
Proteasome subunit beta type-6
L, Z
222Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: PRE7 (PRS3, PTS1)
EC: 3.4.25.1
Find proteins for P23724 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P23724
Entity ID: 13
MoleculeChainsSequence LengthOrganismDetails
Proteasome subunit beta type-7
M, a
233Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: PRE4
EC: 3.4.25.1
Find proteins for P30657 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P30657
Entity ID: 14
MoleculeChainsSequence LengthOrganismDetails
Proteasome subunit beta type-1
N, b
196Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: PRE3
EC: 3.4.25.1
Find proteins for P38624 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P38624
Entity ID: 15
MoleculeChainsSequence LengthOrganismDetails
TMC-95A mimic ligand yCP:4a fragment P
c
4N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Entity ID: 16
MoleculeChainsSequence LengthOrganismDetails
TMC-95A mimic ligand yCP:4a fragment Q
d
7N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
0L1
Query on 0L1
Download SDF File
Download CCD File
c
hexanedioic acid
Adipic acid
C6 H10 O4
WNLRTRBMVRJNCN-UHFFFAOYSA-N
 Ligand Interaction
MES
Query on MES
Download SDF File
Download CCD File
K, Y
2-(N-MORPHOLINO)-ETHANESULFONIC ACID
C6 H13 N O4 S
SXGZJKUKBWWHRA-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.1 Å
  • R-Value Free: 0.223
  • R-Value Work: 0.216
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 135.700α = 90.00
b = 301.400β = 112.80
c = 144.600γ = 90.00
Software Package:
Software NamePurpose
REFMACrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots


View more in-depth experimental data

Entry History

Deposition Data

Revision History

  • Version 1.0: 2013-05-01
    Type: Initial release
  • Version 1.1: 2013-06-05
    Type: Structure summary
