4FKW | pdb_00004fkw

Crystal structure of the cdk2 in complex with oxindole inhibitor

• PDB DOI: https://doi.org/10.2210/pdb4FKW/pdb

• Classification: TRANSFERASE/TRANSFERASE INHIBITOR
• Organism(s): Homo sapiens
• Expression System: Trichoplusia ni
• Mutation(s): Yes


• Deposited: 2012-06-13 Released: 2013-05-08
• Deposition Author(s): Kang, Y.N., Stuckey, J.A.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free:
  0.204 (Depositor), 0.208 (DCC)
• R-Value Work:
  0.177 (Depositor), 0.176 (DCC)
• R-Value Observed:
  0.179 (Depositor)

Literature

Crystal structure of the cdk2 in complex with oxindole inhibitor

Kang, Y.N., Stuckey, J.A.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 34.51 kDa
• Atom Count: 2,521
• Modeled Residue Count: 281
• Deposited Residue Count: 299
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cyclin-dependent kinase 2	A	299	Homo sapiens	Mutation(s): 1  Gene Names: CDK2, CDKN2 EC: 2.7.11.22
UniProt & NIH Common Fund Data Resources
Find proteins for P24941 (Homo sapiens) Explore P24941  Go to UniProtKB:  P24941
PHAROS:  P24941 GTEx:  ENSG00000123374

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
62K	B [auth A]	2-methylpropyl (3Z)-2-oxo-3-[2-(4-sulfamoylphenyl)hydrazinylidene]-2,3-dihydro-1H-indole-5-carboxylate C19 H20 N4 O5 S JQMQQPJLUPJHES-UHFFFAOYSA-N
GOL	C [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N

Binding Affinity Annotations
ID	Source	Binding Affinity
62K	BindingDB:  4FKW	Kd: 47.3 (nM) from 1 assay(s)

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free:  0.204 (Depositor), 0.208 (DCC)
• R-Value Work:  0.177 (Depositor), 0.176 (DCC)
• R-Value Observed: 0.179 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 53.722	α = 90
b = 71.963	β = 90
c = 72.186	γ = 90

Software Package:

Software Name	Purpose
MD2	data collection
PHASER	phasing
BUSTER	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2013-05-08
Deposition Author(s): Kang, Y.N., Stuckey, J.A.

Revision History

• Version 1.0: 2013-05-08
  Type: Initial release

• Version 1.1: 2013-05-22
  Changes: Other
• Version 1.2: 2024-11-20
  Changes: Data collection, Database references, Derived calculations, Structure summary
