4E5Z

Damaged DNA induced UV-damaged DNA-binding protein (UV-DDB) dimerization and its roles in chromatinized DNA repair

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.22 Å
  • R-Value Free: 0.284
  • R-Value Work: 0.228
  • R-Value Observed: 0.230

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history.


Literature

Damaged DNA induced UV-damaged DNA-binding protein (UV-DDB) dimerization and its roles in chromatinized DNA repair.

Yeh, J.I., Levine, A.S., Du, S., Chinte, U., Ghodke, H., Wang, H., Shi, H., Hsieh, C.L., Conway, J.F., Van Houten, B., Rapic-Otrin, V.

(2012) Proc Natl Acad Sci U S A 109: E2737-E2746

  • DOI: 10.1073/pnas.1110067109
  • Primary Citation of Related Structures:
    4E54, 4E5Z

  • PubMed Abstract:

    • UV light-induced photoproducts are recognized and removed by the nucleotide-excision repair (NER) pathway. In humans, the UV-damaged DNA-binding protein (UV-DDB) is part of a ubiquitin E3 ligase complex (DDB1-CUL4A(DDB2)) that initiates NER by recognizing damaged chromatin with concomitant ubiquitination of core histones at the lesion ...

    UV light-induced photoproducts are recognized and removed by the nucleotide-excision repair (NER) pathway. In humans, the UV-damaged DNA-binding protein (UV-DDB) is part of a ubiquitin E3 ligase complex (DDB1-CUL4A(DDB2)) that initiates NER by recognizing damaged chromatin with concomitant ubiquitination of core histones at the lesion. We report the X-ray crystal structure of the human UV-DDB in a complex with damaged DNA and show that the N-terminal domain of DDB2 makes critical contacts with two molecules of DNA, driving N-terminal-domain folding and promoting UV-DDB dimerization. The functional significance of the dimeric UV-DDB [(DDB1-DDB2)(2)], in a complex with damaged DNA, is validated by electron microscopy, atomic force microscopy, solution biophysical, and functional analyses. We propose that the binding of UV-damaged DNA results in conformational changes in the N-terminal domain of DDB2, inducing helical folding in the context of the bound DNA and inducing dimerization as a function of nucleotide binding. The temporal and spatial interplay between domain ordering and dimerization provides an elegant molecular rationale for the unprecedented binding affinities and selectivities exhibited by UV-DDB for UV-damaged DNA. Modeling the DDB1-CUL4A(DDB2) complex according to the dimeric UV-DDB-AP24 architecture results in a mechanistically consistent alignment of the E3 ligase bound to a nucleosome harboring damaged DNA. Our findings provide unique structural and conformational insights into the molecular architecture of the DDB1-CUL4A(DDB2) E3 ligase, with significant implications for the regulation and overall organization of the proteins responsible for initiation of NER in the context of chromatin and for the consequent maintenance of genomic integrity.

    Organizational Affiliation:

    Department of Structural Biology, University of Pittsburgh School of Medicine, Pittsburgh, PA 15260, USA. jiyeh@pitt.edu



Macromolecules

Find similar proteins by:
(by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
DNA damage-binding protein 1A1150Homo sapiensMutation(s): 0
Gene Names: DDB1, DDB1_HUMAN, Q16531, XAP1
UniProt & NIH Common Fund Data Resources
Find proteins for Q16531 (Homo sapiens)
Explore Q16531
Go to UniProtKB:  Q16531
PHAROS:  Q16531
GTEx:  ENSG00000167986
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
DNA damage-binding protein 2B436Homo sapiensMutation(s): 0
Gene Names: DDB2
UniProt & NIH Common Fund Data Resources
Find proteins for Q92466 (Homo sapiens)
Explore Q92466
Go to UniProtKB:  Q92466
PHAROS:  Q92466
GTEx:  ENSG00000134574
Protein Feature View
Expand
  • Reference Sequence
Find similar nucleic acids by:
(by identity cutoff)  |  Structure
Entity ID: 3
MoleculeChainsLengthOrganismImage
AP24 DNA strandC [auth F]24N/A
Protein Feature View
Expand
  • Reference Sequence
Find similar nucleic acids by:
(by identity cutoff)  |  Structure
Entity ID: 4
MoleculeChainsLengthOrganismImage
AP24 DNA complementary strandD [auth G]24N/A
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.22 Å
  • R-Value Free: 0.284
  • R-Value Work: 0.228
  • R-Value Observed: 0.230
  • Space Group: P 21 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 72.418α = 90
b = 76.504β = 90
c = 389.738γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
SOLVEphasing
REFMACrefinement
HKL-2000data reduction
SCALEPACKdata scaling
ADSCdata collection

Structure Validation

View Full Validation Report



View more in-depth experimental data

Entry History

Deposition Data

  • Deposited Date: 2012-03-15
  • Released Date: 2012-08-22
    • Deposition Author(s): Yeh, J.I., Du, S.

Revision History  (Full details and data files)

  • Version 1.0: 2012-08-22
    Type: Initial release
  • Version 1.1: 2012-10-24
    Changes: Database references
  • Version 1.2: 2019-07-17
    Changes: Data collection, Derived calculations, Refinement description
