4BTA

CRYSTAL STRUCTURE OF THE PEPTIDE(PRO-PRO-GLY)3 BOUND COMPLEX OF N- TERMINAL DOMAIN AND PEPTIDE SUBSTRATE BINDING DOMAIN OF PROLYL-4 HYDROXYLASE (RESIDUES 1-244) TYPE I FROM HUMAN


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.95 Å
  • R-Value Free: 0.279
  • R-Value Work: 0.227

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

The Structural Motifs for Substrate Binding and Dimerization of the Alpha Subunit of Collagen Prolyl 4-Hydroxylase

Anantharajan, J.Koski, M.K.Kursula, P.Hieta, R.Bergmann, U.Myllyharju, J.Wierenga, R.K.

(2013) Structure 21: 2107

  • DOI: 10.1016/j.str.2013.09.005
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Collagen prolyl 4-hydroxylase (C-P4H) catalyzes the proline hydroxylation of procollagen, an essential modification in the maturation of collagens. C-P4H consists of two catalytic α subunits and two protein disulfide isomerase β subunits. The assembl ...

    Collagen prolyl 4-hydroxylase (C-P4H) catalyzes the proline hydroxylation of procollagen, an essential modification in the maturation of collagens. C-P4H consists of two catalytic α subunits and two protein disulfide isomerase β subunits. The assembly of these subunits is unknown. The α subunit contains an N domain (1-143), a peptide-substrate-binding-domain (PSB, 144-244) and a catalytic domain (245-517). Here, we report the dimeric structure of the N-terminal region (1-244) of the α subunit. It is shown that the N domain has an important role in the assembly of the C-P4H tetramer, by forming an extended four-helix bundle that includes an antiparallel coiled-coil dimerization motif between the two α subunits. Complexes of this construct with a C-P4H inhibitor and substrate show the mode of peptide-binding to the PSB domain. Both peptides adopt a poly-(L)-proline-type-II helix conformation and bind in a curved, asymmetric groove lined by conserved tyrosines and an Arg-Asp salt bridge.


    Organizational Affiliation

    Biocenter Oulu and Department of Biochemistry, University of Oulu, P.O. Box 3000, FIN-90014 Oulu, Finland.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
PROLYL 4-HYDROXYLASE SUBUNIT ALPHA-1
A, B
251Homo sapiensMutation(s): 0
Gene Names: P4HA1 (P4HA)
EC: 1.14.11.2
Find proteins for P13674 (Homo sapiens)
Go to Gene View: P4HA1
Go to UniProtKB:  P13674
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
PROLINE RICH PEPTIDE
C
9N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.95 Å
  • R-Value Free: 0.279
  • R-Value Work: 0.227
  • Space Group: P 21 21 2
Unit Cell:
Length (Å)Angle (°)
a = 234.660α = 90.00
b = 47.850β = 90.00
c = 60.290γ = 90.00
Software Package:
Software NamePurpose
XDSdata reduction
PHASERphasing
PHENIXrefinement
XDSdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2013-10-09
    Type: Initial release
  • Version 1.1: 2013-10-16
    Type: Database references
  • Version 1.2: 2013-11-20
    Type: Database references
  • Version 1.3: 2013-12-25
    Type: Database references
