4BBR

Structure of RNA polymerase II-TFIIB complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.40 Å
  • R-Value Free: 0.211
  • R-Value Work: 0.174
  • R-Value Observed: 0.175

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Structure and Function of the Initially Transcribing RNA Polymerase II-TFIIB Complex

Sainsbury, S.Niesser, J.Cramer, P.

(2013) Nature 493: 437

  • DOI: 10.1038/nature11715
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • The general transcription factor (TF) IIB is required for RNA polymerase (Pol) II initiation and extends with its B-reader element into the Pol II active centre cleft. Low-resolution structures of the Pol II-TFIIB complex indicated how TFIIB function ...

    The general transcription factor (TF) IIB is required for RNA polymerase (Pol) II initiation and extends with its B-reader element into the Pol II active centre cleft. Low-resolution structures of the Pol II-TFIIB complex indicated how TFIIB functions in DNA recruitment, but they lacked nucleic acids and half of the B-reader, leaving other TFIIB functions enigmatic. Here we report crystal structures of the Pol II-TFIIB complex from the yeast Saccharomyces cerevisiae at 3.4 Å resolution and of an initially transcribing complex that additionally contains the DNA template and a 6-nucleotide RNA product. The structures reveal the entire B-reader and protein-nucleic acid interactions, and together with functional data lead to a more complete understanding of transcription initiation. TFIIB partially closes the polymerase cleft to position DNA and assist in its opening. The B-reader does not reach the active site but binds the DNA template strand upstream to assist in the recognition of the initiator sequence and in positioning the transcription start site. TFIIB rearranges active-site residues, induces binding of the catalytic metal ion B, and stimulates initial RNA synthesis allosterically. TFIIB then prevents the emerging DNA-RNA hybrid duplex from tilting, which would impair RNA synthesis. When the RNA grows beyond 6 nucleotides, it is separated from DNA and is directed to its exit tunnel by the B-reader loop. Once the RNA grows to 12-13 nucleotides, it clashes with TFIIB, triggering TFIIB displacement and elongation complex formation. Similar mechanisms may underlie all cellular transcription because all eukaryotic and archaeal RNA polymerases use TFIIB-like factors, and the bacterial initiation factor sigma has TFIIB-like topology and contains the loop region 3.2 that resembles the B-reader loop in location, charge and function. TFIIB and its counterparts may thus account for the two fundamental properties that distinguish RNA from DNA polymerases: primer-independent chain initiation and product separation from the template.


    Organizational Affiliation

    Gene Center and Department of Biochemistry, Center for Integrated Protein Science CIPSM, Ludwig-Maximilians-Universität München, Feodor-Lynen-Str. 25, 81377 Munich, Germany.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASE II SUBUNIT RPB1A1733Saccharomyces cerevisiaeMutation(s): 0
EC: 2.7.7.6
Find proteins for P04050 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P04050
Go to UniProtKB:  P04050
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASE II SUBUNIT RPB2B1224Saccharomyces cerevisiaeMutation(s): 0
EC: 2.7.7.6
Find proteins for P08518 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P08518
Go to UniProtKB:  P08518
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASE II SUBUNIT RPB3C318Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P16370 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P16370
Go to UniProtKB:  P16370
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASE II SUBUNIT RPB4D221Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P20433 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P20433
Go to UniProtKB:  P20433
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 5
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASES I, II, AND III SUBUNIT RPABC 1E215Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P20434 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P20434
Go to UniProtKB:  P20434
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 6
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASES I, II, AND III SUBUNIT RPABC 2F155Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P20435 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P20435
Go to UniProtKB:  P20435
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 7
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASE II SUBUNIT RPB7G171Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P34087 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P34087
Go to UniProtKB:  P34087
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 8
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASES I, II, AND III SUBUNIT RPABC 3H146Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P20436 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P20436
Go to UniProtKB:  P20436
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 9
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASE II SUBUNIT RPB9I122Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P27999 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P27999
Go to UniProtKB:  P27999
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 10
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASES I, II, AND III SUBUNIT RPABC 5J70Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P22139 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P22139
Go to UniProtKB:  P22139
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 11
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASE II SUBUNIT RPB11K120Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P38902 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P38902
Go to UniProtKB:  P38902
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 12
MoleculeChainsSequence LengthOrganismDetails
DNA-DIRECTED RNA POLYMERASES I, II, AND III SUBUNIT RPABC 4L70Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P40422 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P40422
Go to UniProtKB:  P40422
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 13
MoleculeChainsSequence LengthOrganismDetails
TRANSCRIPTION INITIATION FACTOR IIBM345Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P29055 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P29055
Go to UniProtKB:  P29055
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download CCD File
A, B, C, I, J, L, M
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
MG
Query on MG

Download CCD File
A
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.40 Å
  • R-Value Free: 0.211
  • R-Value Work: 0.174
  • R-Value Observed: 0.175
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 222.44α = 90
b = 386.76β = 90
c = 254.35γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2012-11-14
    Type: Initial release
  • Version 1.1: 2012-11-28
    Changes: Database references
  • Version 1.2: 2013-01-30
    Changes: Database references
  • Version 1.3: 2019-11-20
    Changes: Derived calculations, Other
