3F6G

Crystal structure of the regulatory domain of LiCMS in complexed with isoleucine - type II


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.263
  • R-Value Work: 0.226
  • R-Value Observed: 0.227

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Molecular basis of the inhibitor selectivity and insights into the feedback inhibition mechanism of citramalate synthase from Leptospira interrogans

Zhang, P.Ma, J.Zhang, Z.Zha, M.Xu, H.Zhao, G.Ding, J.

(2009) Biochem J 421: 133-143

  • DOI: 10.1042/BJ20090336
  • Primary Citation of Related Structures:
    3F6G, 3F6H

  • PubMed Abstract:
  • LiCMS (Leptospira interrogans citramalate synthase) catalyses the first reaction of the isoleucine biosynthesis pathway in L. interrogans, the pathogen of leptospirosis. The catalytic reaction is regulated through feedback inhibition by its end product isoleucine ...

    LiCMS (Leptospira interrogans citramalate synthase) catalyses the first reaction of the isoleucine biosynthesis pathway in L. interrogans, the pathogen of leptospirosis. The catalytic reaction is regulated through feedback inhibition by its end product isoleucine. To understand the molecular basis of the high selectivity of the inhibitor and the mechanism of feedback inhibition, we determined the crystal structure of LiCMSC (C-terminal regulatory domain of LiCMS) in complex with isoleucine, and performed a biochemical study of the inhibition of LiCMS using mutagenesis and kinetic methods. LiCMSC forms a dimer of dimers in both the crystal structure and solution and the dimeric LiCMSC is the basic functional unit. LiCMSC consists of six beta-strands forming two anti-parallel beta-sheets and two alpha-helices and assumes a betaalphabeta three-layer sandwich structure. The inhibitor isoleucine is bound in a pocket at the dimer interface and has both hydrophobic and hydrogen-bonding interactions with several conserved residues of both subunits. The high selectivity of LiCMS for isoleucine over leucine is primarily dictated by the residues, Tyr430, Leu451, Tyr454, Ile458 and Val468, that form a hydrophobic pocket to accommodate the side chain of the inhibitor. The binding of isoleucine has inhibitory effects on the binding of both the substrate, pyruvate, and coenzyme, acetyl-CoA, in a typical pattern of K-type inhibition. The structural and biochemical data from the present study together suggest that the binding of isoleucine affects the binding of the substrate and coenzyme at the active site, possibly via conformational change of the dimer interface of the regulatory domain, leading to inhibition of the catalytic reaction.


    Organizational Affiliation

    State Key Laboratory of Molecular Biology and Research Center for Structural Biology, Institute of Biochemistry and Cell Biology, Shanghai Institutes for Biological Sciences, Chinese Academy of Sciences, 320 Yue-Yang Road, Shanghai 200031, China.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Alpha-isopropylmalate synthaseB [auth A], A [auth B]127Leptospira interrogansMutation(s): 0
Gene Names: cimA
EC: 2.3.1.182
UniProt
Find proteins for Q8F3Q1 (Leptospira interrogans serogroup Icterohaemorrhagiae serovar Lai (strain 56601))
Explore Q8F3Q1
Go to UniProtKB:  Q8F3Q1
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.263
  • R-Value Work: 0.226
  • R-Value Observed: 0.227
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 61.315α = 90
b = 97.943β = 91.38
c = 39.974γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
CrystalCleardata collection
CrystalCleardata reduction
CrystalCleardata scaling
CNSphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-04-21
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
