3BIX

Crystal structure of the extracellular esterase domain of Neuroligin-1

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.205
  • R-Value Work: 0.185

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history.


Literature

Structures of Neuroligin-1 and the Neuroligin-1/Neurexin-1beta Complex Reveal Specific Protein-Protein and Protein-Ca(2+) Interactions.

Arac, D., Boucard, A.A., Ozkan, E., Strop, P., Newell, E., Sudhof, T.C., Brunger, A.T.

(2007) Neuron 56: 992-1003

  • DOI: 10.1016/j.neuron.2007.12.002
  • Primary Citation of Related Structures:
    3BIW, 3BIX

  • PubMed Abstract:

    • Neurexins and neuroligins provide trans-synaptic connectivity by the Ca2+-dependent interaction of their alternatively spliced extracellular domains. Neuroligins specify synapses in an activity-dependent manner, presumably by binding to neurexins. Here, we present the crystal structures of neuroligin-1 in isolation and in complex with neurexin-1 beta ...

    Neurexins and neuroligins provide trans-synaptic connectivity by the Ca2+-dependent interaction of their alternatively spliced extracellular domains. Neuroligins specify synapses in an activity-dependent manner, presumably by binding to neurexins. Here, we present the crystal structures of neuroligin-1 in isolation and in complex with neurexin-1 beta. Neuroligin-1 forms a constitutive dimer, and two neurexin-1 beta monomers bind to two identical surfaces on the opposite faces of the neuroligin-1 dimer to form a heterotetramer. The neuroligin-1/neurexin-1 beta complex exhibits a nanomolar affinity and includes a large binding interface that contains bound Ca2+. Alternatively spliced sites in neurexin-1 beta and in neuroligin-1 are positioned nearby the binding interface, explaining how they regulate the interaction. Structure-based mutations of neuroligin-1 at the interface disrupt binding to neurexin-1 beta, but not the folding of neuroligin-1 and confirm the validity of the binding interface of the neuroligin-1/neurexin-1 beta complex. Our results provide molecular insights for understanding the role of cell-adhesion proteins in synapse function.

    Organizational Affiliation:

    Howard Hughes Medical Institute, Stanford University, Stanford, CA 94305, USA.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Neuroligin-1A, B, C, D574Rattus norvegicusMutation(s): 0
Gene Names: Nlgn1
UniProt
Find proteins for Q62765 (Rattus norvegicus)
Explore Q62765
Go to UniProtKB:  Q62765
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ62765
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NAG
Query on NAG
Download Ideal Coordinates CCD File
E [auth A],
F [auth A],
K [auth B],
L [auth B],
Q [auth C],
E [auth A],
F [auth A],
K [auth B],
L [auth B],
Q [auth C],
R [auth C],
W [auth D],
X [auth D]
2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N		 Ligand Interaction
EDO
Query on EDO
Download Ideal Coordinates CCD File
AA [auth D],
BA [auth D],
H [auth A],
I [auth A],
J [auth A],
AA [auth D],
BA [auth D],
H [auth A],
I [auth A],
J [auth A],
N [auth B],
O [auth B],
P [auth B],
S [auth C],
T [auth C],
U [auth C],
V [auth C],
Y [auth D],
Z [auth D]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N		 Ligand Interaction
NI
Query on NI
Download Ideal Coordinates CCD File
G [auth A],
M [auth B]		NICKEL (II) ION
Ni
VEQPNABPJHWNSG-UHFFFAOYSA-N		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.205
  • R-Value Work: 0.185
  • Space Group: P 32
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 173.744α = 90
b = 173.744β = 90
c = 108.045γ = 120
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
PHASERphasing
CNSrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


View more in-depth experimental data

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2007-12-18
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Non-polymer description, Version format compliance
  • Version 1.2: 2017-08-23
    Changes: Refinement description, Source and taxonomy
  • Version 1.3: 2017-10-25
    Changes: Refinement description
  • Version 1.4: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Data collection, Database references, Derived calculations, Structure summary
