3U1D | pdb_00003u1d

The structure of a protein with a GntR superfamily winged-helix-turn-helix domain from Halomicrobium mukohataei.

• PDB DOI: https://doi.org/10.2210/pdb3U1D/pdb

• Classification: Structural Genomics, Unknown Function
• Organism(s): Halomicrobium mukohataei DSM 12286
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2011-09-29 Released: 2011-12-07
• Deposition Author(s): Cuff, M.E., Bigelow, L., Bearden, J., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free:
  0.194 (Depositor), 0.203 (DCC)
• R-Value Work:
  0.171 (Depositor), 0.180 (DCC)
• R-Value Observed:
  0.173 (Depositor)

Literature

The structure of a protein with a GntR superfamily winged-helix-turn-helix domain from Halomicrobium mukohataei.

Cuff, M.E., Bigelow, L., Bearden, J., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 35.5 kDa
• Atom Count: 2,723
• Modeled Residue Count: 291
• Deposited Residue Count: 302
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
uncharacterized protein	A, B	151	Halomicrobium mukohataei DSM 12286	Mutation(s): 0  Gene Names: Hmuk_3159
UniProt
Find proteins for C7P2E9 (Halomicrobium mukohataei (strain ATCC 700874 / DSM 12286 / JCM 9738 / NCIMB 13541)) Explore C7P2E9  Go to UniProtKB:  C7P2E9

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
TRS	J [auth B], K [auth B]	2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL C4 H12 N O3 LENZDBCJOHFCAS-UHFFFAOYSA-O
PEG	F [auth A]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
EDO	G [auth B], L [auth B], M [auth B]	1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N
CL	C [auth A], D [auth A], E [auth A], H [auth B], I [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.80 Å
• R-Value Free:  0.194 (Depositor), 0.203 (DCC)
• R-Value Work:  0.171 (Depositor), 0.180 (DCC)
• R-Value Observed: 0.173 (Depositor)

Space Group: P 4₃ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 57.214	α = 90
b = 57.214	β = 90
c = 218.354	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
MLPHARE	phasing
DM	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
SBC-Collect	data collection
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing
SHELXD	phasing
SHELXE	model building
SOLVE	phasing
RESOLVE	phasing
ARP/wARP	model building
CCP4	phasing
O	model building
Coot	model building

Structure Validation

Entry History

Deposition Data

• Released Date: 2011-12-07
Deposition Author(s): Cuff, M.E., Bigelow, L., Bearden, J., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2011-12-07
  Type: Initial release

• Version 1.1: 2017-11-08
  Changes: Refinement description
• Version 1.2: 2024-10-30
  Changes: Data collection, Database references, Derived calculations, Structure summary
