Biological Assembly 1

 3D View: Structure | Electron Density | Ligand Interaction

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

 3D View: Structure | Electron Density | Ligand Interaction

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 108.15 kDa
• Atom Count: 7633
• Residue Count: 925
• Unique protein chains: 2

3S97

PTPRZ CNTN1 complex

• DOI: 10.2210/pdb3S97/pdb

• Classification: CELL ADHESION
• Organism(s): Homo sapiens
• Expression System: Escherichia coli, Homo sapiens
• Mutation(s): No


• Deposited: 2011-05-31 Released: 2011-09-28
• Deposition Author(s): Bouyain, S.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free: 0.255
• R-Value Work: 0.201
• R-Value Observed: 0.203

Literature

A complex between contactin-1 and the protein tyrosine phosphatase PTPRZ controls the development of oligodendrocyte precursor cells.

Lamprianou, S., Chatzopoulou, E., Thomas, J.L., Bouyain, S., Harroch, S.

(2011) Proc Natl Acad Sci U S A 108: 17498-17503

• PubMed: 21969550
• DOI: 10.1073/pnas.1108774108
• Primary Citation of Related Structures:
  3S97


• PubMed Abstract:


The six members of the contactin (CNTN) family of neural cell adhesion molecules are involved in the formation and maintenance of the central nervous system (CNS) and have been linked to mental retardation and neuropsychiatric disorders such as autism. Five of the six CNTNs bind to the homologous receptor protein tyrosine phosphatases gamma (PTPRG) and zeta (PTPRZ), but the biological roles of these interactions remain unclear. We report here the cocrystal structure of the carbonic anhydrase-like domain of PTPRZ bound to tandem Ig repeats of CNTN1 and combine these structural data with binding assays to show that PTPRZ binds specifically to CNTN1 expressed at the surface of oligodendrocyte precursor cells. Furthermore, analyses of glial cell populations in wild-type and PTPRZ-deficient mice show that the binding of PTPRZ to CNTN1 expressed at the surface of oligodendrocyte precursor cells inhibits their proliferation and promotes their development into mature oligodendrocytes. Overall, these results implicate the PTPRZ/CNTN1 complex as a previously unknown modulator of oligodendrogenesis.

---

Organizational Affiliation:

Départment de Neuroscience, Institut Pasteur de Paris, 75624 Paris, France.

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Receptor-type tyrosine-protein phosphatase zeta	A, B	273	Homo sapiens	Mutation(s): 0  Gene Names: HTPZP2, PTPRZ, PTPRZ1, PTPRZ2, PTPZ EC: 3.1.3.48
Find proteins for P23471 (Homo sapiens) Explore P23471  Go to UniProtKB:  P23471
NIH Common Fund Data Resources
PHAROS:  P23471 GTEx:  ENSG00000106278

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Contactin-1	C, D	201	Homo sapiens	Mutation(s): 0  Gene Names: CNTN1
Find proteins for Q12860 (Homo sapiens) Explore Q12860  Go to UniProtKB:  Q12860
NIH Common Fund Data Resources
PHAROS:  Q12860 GTEx:  ENSG00000018236

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
NAG	C, D	2-acetamido-2-deoxy-beta-D-glucopyranose C8 H15 N O6 OVRNDRQMDRJTHS-FMDGEEDCSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free: 0.255
• R-Value Work: 0.201
• R-Value Observed: 0.203
• Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 334.108	α = 90
b = 45.957	β = 101.37
c = 78.947	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
PHASER	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction
HKL-2000	data collection
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

Entry History

Deposition Data

• Deposited Date: 2011-05-31
• Released Date: 2011-09-28
Deposition Author(s): Bouyain, S.

Revision History

• Version 1.0: 2011-09-28
  Type: Initial release

• Version 1.1: 2011-10-19
  Changes: Database references
• Version 1.2: 2011-11-02
  Changes: Database references
• Version 1.3: 2017-11-08
  Changes: Refinement description
• Version 1.4: 2020-07-29
  Type: Remediation
  Reason: Carbohydrate remediation
  Changes: Data collection, Database references, Derived calculations, Structure summary
