3R12 | pdb_00003r12

Crystal structure of a Deoxyribose-phosphate aldolase (TM_1559) from THERMOTOGA MARITIMA at 1.75 A resolution

PDB DOI: https://doi.org/10.2210/pdb3R12/pdb
Entry: 3R12 supersedes: 1O0Y

Classification: LYASE
Organism(s): Thermotoga maritima
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2011-03-09 Released: 2011-04-20
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.75 Å
R-Value Free:
0.192 (Depositor), 0.193 (DCC)
R-Value Work:
0.153 (Depositor), 0.159 (DCC)
R-Value Observed:
0.155 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3R12

This is version 1.5 of the entry. See complete history.

Literature

Crystal structure of a Deoxyribose-phosphate aldolase (TM_1559) from THERMOTOGA MARITIMA at 1.75 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 58.87 kDa
Atom Count: 4,339
Modeled Residue Count: 510
Deposited Residue Count: 520
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Deoxyribose-phosphate aldolase	A, B	260	Thermotoga maritima	Mutation(s): 0 Gene Names: deoC, TM1559, TM_1559 EC: 4.1.2.4
UniProt
Find proteins for Q9X1P5 (Thermotoga maritima (strain ATCC 43589 / DSM 3109 / JCM 10099 / NBRC 100826 / MSB8)) Explore Q9X1P5 Go to UniProtKB: Q9X1P5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9X1P5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CIT Query on CIT Download:Ideal Coordinates CCD File SDF format, chain F [auth B] SDF format, chain C [auth A] MOL2 format, chain F [auth B] MOL2 format, chain C [auth A] mmCIF format, chain F [auth B] mmCIF format, chain C [auth A]	C [auth A], F [auth B]	CITRIC ACID C₆ H₈ O₇ KRKNYBCHXYNGOX-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain F [auth B] Interactions & Density Focus chain C [auth A] Focus chain F [auth B]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
PGO Query on PGO Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	S-1,2-PROPANEDIOL C₃ H₈ O₂ DNIAPMSPPWPWGF-VKHMYHEASA-N		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.75 Å
R-Value Free: 0.192 (Depositor), 0.193 (DCC)
R-Value Work: 0.153 (Depositor), 0.159 (DCC)
R-Value Observed: 0.155 (Depositor)

Diffraction Data:

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 53.812	α = 90
b = 51.818	β = 95.23
c = 84.735	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
SHELX	phasing
SHARP	phasing
XSCALE	data scaling
REFMAC	refinement
XDS	data reduction
SHELXD	phasing
autoSHARP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2011-04-20

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

This entry supersedes: 1O0Y

Revision History (Full details and data files)

Version 1.0: 2011-04-20
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2011-07-20
Changes: Structure summary
Version 1.3: 2017-11-08
Changes: Refinement description
Version 1.4: 2023-02-01
Changes: Database references, Derived calculations
Version 1.5: 2024-11-20
Changes: Data collection, Structure summary
