3QNJ

Crystal structure of the substrate binding domain of E.coli DnaK in complex with the antimicrobial peptide oncocin


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.28 Å
  • R-Value Free: 0.284
  • R-Value Work: 0.211

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Rational Design of Oncocin Derivatives with Superior Protease Stabilities and Antibacterial Activities Based on the High-Resolution Structure of the Oncocin-DnaK Complex.

Knappe, D.Zahn, M.Sauer, U.Schiffer, G.Strater, N.Hoffmann, R.

(2011) Chembiochem 12: 874-876


Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Chaperone protein DnaK
A, B
219Escherichia coli (strain K12)Gene Names: dnaK (groP, grpF, seg)
Find proteins for P0A6Y8 (Escherichia coli (strain K12))
Go to UniProtKB:  P0A6Y8
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
antimicrobial peptide oncocin
C, D
19N/AN/A
Protein Feature View is not available: No corresponding UniProt sequence found.
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A, B, C
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
ORN
Query on ORN
C, D
L-PEPTIDE LINKINGC5 H12 N2 O2ALA
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.28 Å
  • R-Value Free: 0.284
  • R-Value Work: 0.211
  • Space Group: P 21 21 2
Unit Cell:
Length (Å)Angle (°)
a = 77.664α = 90.00
b = 161.137β = 90.00
c = 44.629γ = 90.00
Software Package:
Software NamePurpose
XDSdata reduction
MOLREPphasing
REFMACrefinement
SCALAdata scaling
MAR345data collection

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

  • Deposited Date: 2011-02-08
  • Released Date: 2011-03-23
  • Deposition Author(s): Zahn, M., Straeter, N.

Revision History

  • Version 1.0: 2011-03-23
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
  • Version 1.2: 2017-11-08
    Type: Refinement description
