3QH9

Human Liprin-beta2 Coiled-Coil


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.01 Å
  • R-Value Free: 0.298
  • R-Value Work: 0.232

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Crystal structure of the central coiled-coil domain from human liprin-beta2

Stafford, R.L.Tang, M.Y.Sawaya, M.R.Phillips, M.L.Bowie, J.U.

(2011) Biochemistry 50: 3807-3815

  • DOI: 10.1021/bi200141e

  • PubMed Abstract:
  • Liprins are a conserved family of scaffolding proteins important for the proper regulation and development of neuronal synapses. Humans have four liprin-αs and two liprin-βs which all contain long coiled-coil domains followed by three tandem SAM doma ...

    Liprins are a conserved family of scaffolding proteins important for the proper regulation and development of neuronal synapses. Humans have four liprin-αs and two liprin-βs which all contain long coiled-coil domains followed by three tandem SAM domains. Complex interactions between the coiled-coil and SAM domains are thought to create liprin scaffolds, but the structural and biochemical properties of these domains remain largely uncharacterized. In this study we find that the human liprin-β2 coiled-coil forms an extended dimer. Several protease-resistant subdomains within the liprin-β1 and liprin-β2 coiled-coils were also identified. A 2.0 Å crystal structure of the central, protease-resistant core of the liprin-β2 coiled-coil reveals a parallel helix orientation. These studies represent an initial step toward determining the overall architecture of liprin scaffolds and understanding the molecular basis for their synaptic functions.


    Organizational Affiliation

    Department of Chemistry and Biochemistry, UCLA-DOE Institute of Genomics and Proteomics, Molecular Biology Institute, University of California, Los Angeles, Boyer Hall 611 Charles E. Young Dr. E., Los Angeles, California 90095-1570, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Liprin-beta-2
A
81Homo sapiensMutation(s): 0
Gene Names: PPFIBP2
Find proteins for Q8ND30 (Homo sapiens)
Go to Gene View: PPFIBP2
Go to UniProtKB:  Q8ND30
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
IOD
Query on IOD

Download SDF File
Download CCD File
A
IODIDE ION
I
XMBWDFGMSWQBCA-UHFFFAOYSA-M
 Ligand Interaction
GOL
Query on GOL

Download SDF File
Download CCD File
A
GLYCEROL
GLYCERIN; PROPANE-1,2,3-TRIOL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
NH4
Query on NH4

Download SDF File
Download CCD File
A
AMMONIUM ION
H4 N
QGZKDVFQNNGYKY-UHFFFAOYSA-O
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.01 Å
  • R-Value Free: 0.298
  • R-Value Work: 0.232
  • Space Group: C 2 2 21
Unit Cell:
Length (Å)Angle (°)
a = 29.964α = 90.00
b = 162.656β = 90.00
c = 34.387γ = 90.00
Software Package:
Software NamePurpose
SCALEPACKdata scaling
DENZOdata reduction
PDB_EXTRACTdata extraction
ADSCdata collection
REFMACrefinement
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2011-10-26
    Type: Initial release
