3Q6W

Structure of dually-phosphorylated MET receptor kinase in complex with an MK-2461 analog with specificity for the activated receptor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.75 Å
  • R-Value Free: 0.227
  • R-Value Work: 0.204
  • R-Value Observed: 0.205

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Structural basis for selective small molecule kinase inhibition of activated c-Met.

Rickert, K.W.Patel, S.B.Allison, T.J.Byrne, N.J.Darke, P.L.Ford, R.E.Guerin, D.J.Hall, D.L.Kornienko, M.Lu, J.Munshi, S.K.Reid, J.C.Shipman, J.M.Stanton, E.F.Wilson, K.J.Young, J.R.Soisson, S.M.Lumb, K.J.

(2011) J Biol Chem 286: 11218-11225

  • DOI: 10.1074/jbc.M110.204404
  • Primary Citation of Related Structures:
    3Q6U, 3Q6W, 3R7O

  • PubMed Abstract:
  • The receptor tyrosine kinase c-Met is implicated in oncogenesis and is the target for several small molecule and biologic agents in clinical trials for the treatment of cancer. Binding of the hepatocyte growth factor to the cell surface receptor of c-Met induces activation via autophosphorylation of the kinase domain ...

    The receptor tyrosine kinase c-Met is implicated in oncogenesis and is the target for several small molecule and biologic agents in clinical trials for the treatment of cancer. Binding of the hepatocyte growth factor to the cell surface receptor of c-Met induces activation via autophosphorylation of the kinase domain. Here we describe the structural basis of c-Met activation upon autophosphorylation and the selective small molecule inhibiton of autophosphorylated c-Met. MK-2461 is a potent c-Met inhibitor that is selective for the phosphorylated state of the enzyme. Compound 1 is an MK-2461 analog with a 20-fold enthalpy-driven preference for the autophosphorylated over unphosphorylated c-Met kinase domain. The crystal structure of the unbound kinase domain phosphorylated at Tyr-1234 and Tyr-1235 shows that activation loop phosphorylation leads to the ejection and disorder of the activation loop and rearrangement of helix αC and the G loop to generate a viable active site. Helix αC adopts a orientation different from that seen in activation loop mutants. The crystal structure of the complex formed by the autophosphorylated c-Met kinase domain and compound 1 reveals a significant induced fit conformational change of the G loop and ordering of the activation loop, explaining the selectivity of compound 1 for the autophosphorylated state. The results highlight the role of structural plasticity within the kinase domain in imparting the specificity of ligand binding and provide the framework for structure-guided design of activated c-Met inhibitors.


    Organizational Affiliation

    Global Structural Biology, Merck Research Laboratories, West Point, Pennsylvania 19486, USA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Hepatocyte growth factor receptorA307Homo sapiensMutation(s): 0
Gene Names: MET
EC: 2.7.10.1
UniProt & NIH Common Fund Data Resources
Find proteins for P08581 (Homo sapiens)
Explore P08581
Go to UniProtKB:  P08581
PHAROS:  P08581
GTEx:  ENSG00000105976
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP08581
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
Q6W
Query on Q6W

Download Ideal Coordinates CCD File
B [auth A]3-{5-oxo-3-[1-(piperidin-4-yl)-1H-pyrazol-4-yl]-5H-benzo[4,5]cyclohepta[1,2-b]pyridin-7-yl}-N-(pyridin-2-ylmethyl)propanamide
C31 H30 N6 O2
PCKOOTOQVCFRHS-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
PTR
Query on PTR
A L-PEPTIDE LINKINGC9 H12 N O6 PTYR
Binding Affinity Annotations
IDSourceBinding Affinity
Q6W PDBBind:  3Q6W Kd: 27 (nM) from 1 assay(s)
Binding MOAD:  3Q6W Kd: 27 (nM) from 1 assay(s)
BindingDB:  3Q6W IC50: min: 28, max: 85 (nM) from 2 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.75 Å
  • R-Value Free: 0.227
  • R-Value Work: 0.204
  • R-Value Observed: 0.205
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 42.895α = 90
b = 64.091β = 90
c = 111.107γ = 90
Software Package:
Software NamePurpose
SCALEPACKdata scaling
MOLREPphasing
BUSTER-TNTrefinement
PDB_EXTRACTdata extraction
ADSCdata collection
DENZOdata reduction
HKL-2000data scaling
BUSTERrefinement

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2011-01-19
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2017-11-08
    Changes: Refinement description
