3PZN

Structure of the hyperthermostable endo-1,4-beta-D-mannanase from Thermotoga petrophila RKU-1 with citrate and glycerol

• PDB DOI: https://doi.org/10.2210/pdb3PZN/pdb

• Classification: HYDROLASE
• Organism(s): Thermotoga petrophila RKU-1
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2010-12-14 Released: 2011-12-28
• Deposition Author(s): Santos, C.R., Meza, A.N., Paiva, J.H., Silva, J.C., Ruller, R., Prade, R.A., Squina, F.M., Murakami, M.T.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.50 Å
• R-Value Free: 0.180
• R-Value Work: 0.146
• R-Value Observed: 0.147

Literature

Structural characterization of a novel hyperthermostable endo-1,4-beta-D-mannanase from Thermotoga petrophila RKU-1

Santos, C.R., Meza, A.N., Paiva, J.H., Silva, J.C., Ruller, R., Prade, R.A., Squina, F.M., Murakami, M.T.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 44.5 kDa
• Atom Count: 3,236
• Modelled Residue Count: 363
• Deposited Residue Count: 383
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Mannan endo-1,4-beta-mannosidase. Glycosyl Hydrolase family 5	A	383	Thermotoga petrophila RKU-1	Mutation(s): 0  Gene Names: Tpet_1542 EC: 3.2.1.78
UniProt
Find proteins for A5IMX7 (Thermotoga petrophila (strain ATCC BAA-488 / DSM 13995 / JCM 10881 / RKU-1)) Explore A5IMX7  Go to UniProtKB:  A5IMX7

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
CIT	B [auth A]	CITRIC ACID C6 H8 O7 KRKNYBCHXYNGOX-UHFFFAOYSA-N
GOL	C [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.50 Å
• R-Value Free: 0.180
• R-Value Work: 0.146
• R-Value Observed: 0.147
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 55.11	α = 90
b = 83.689	β = 90
c = 93.21	γ = 90

Software Package:

Software Name	Purpose
MAR345dtb	data collection
MOLREP	phasing
REFMAC	refinement
DENZO	data reduction
SCALEPACK	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2011-12-28
Deposition Author(s): Santos, C.R., Meza, A.N., Paiva, J.H., Silva, J.C., Ruller, R., Prade, R.A., Squina, F.M., Murakami, M.T.

Revision History

• Version 1.0: 2011-12-28
  Type: Initial release

• Version 1.1: 2024-02-21
  Changes: Data collection, Database references, Derived calculations
