3P68

Time-dependent and Protein-directed In Situ Growth of Gold Nanoparticles in a Single Crystal of Lysozyme


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.6 Å
  • R-Value Free: 0.255
  • R-Value Work: 0.217

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Time-dependent, protein-directed growth of gold nanoparticles within a single crystal of lysozyme.

Wei, H.Wang, Z.Zhang, J.House, S.Gao, Y.G.Yang, L.Robinson, H.Tan, L.H.Xing, H.Hou, C.Robertson, I.M.Zuo, J.M.Lu, Y.

(2011) Nat Nanotechnol 6: 93-97

  • DOI: 10.1038/nnano.2010.280
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Gold nanoparticles are useful in biomedical applications due to their distinct optical properties and high chemical stability. Reports of the biogenic formation of gold colloids from gold complexes has also led to an increased level of interest in th ...

    Gold nanoparticles are useful in biomedical applications due to their distinct optical properties and high chemical stability. Reports of the biogenic formation of gold colloids from gold complexes has also led to an increased level of interest in the biomineralization of gold. However, the mechanism responsible for biomolecule-directed gold nanoparticle formation remains unclear due to the lack of structural information about biological systems and the fast kinetics of biomimetic chemical systems in solution. Here we show that intact single crystals of lysozyme can be used to study the time-dependent, protein-directed growth of gold nanoparticles. The protein crystals slow down the growth of the gold nanoparticles, allowing detailed kinetic studies to be carried out, and permit a three-dimensional structural characterization that would be difficult to achieve in solution. Furthermore, we show that additional chemical species can be used to fine-tune the growth rate of the gold nanoparticles.


    Organizational Affiliation

    Department of Chemistry, University of Illinois at Urbana-Champaign, Urbana, Illinois 61801, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Lysozyme C
A
129Gallus gallusGene Names: LYZ
EC: 3.2.1.17
Find proteins for P00698 (Gallus gallus)
Go to Gene View: LYZ
Go to UniProtKB:  P00698
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
AU3
Query on AU3

Download SDF File
Download CCD File
A
GOLD 3+ ION
Au
CBMIPXHVOVTTTL-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.6 Å
  • R-Value Free: 0.255
  • R-Value Work: 0.217
  • Space Group: P 43 21 2
Unit Cell:
Length (Å)Angle (°)
a = 78.400α = 90.00
b = 78.400β = 90.00
c = 37.224γ = 90.00
Software Package:
Software NamePurpose
HKL-2000data collection
MOLREPphasing
X-PLORrefinement
HKL-2000data reduction
SHELXL-97refinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2011-02-09
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
