3LXG

Crystal structure of rat phosphodiesterase 10A in complex with ligand WEB-3


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.3 Å
  • R-Value Free: 0.229
  • R-Value Work: 0.176

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Discovery of imidazo[1,5-a]pyrido[3,2-e]pyrazines as a new class of phosphodiesterase 10A inhibitiors.

Hofgen, N.Stange, H.Schindler, R.Lankau, H.J.Grunwald, C.Langen, B.Egerland, U.Tremmel, P.Pangalos, M.N.Marquis, K.L.Hage, T.Harrison, B.L.Malamas, M.S.Brandon, N.J.Kronbach, T.

(2010) J.Med.Chem. 53: 4399-4411

  • DOI: 10.1021/jm1002793

  • PubMed Abstract:
  • Novel imidazo[1,5-a]pyrido[3,2-e]pyrazines have been synthesized and characterized as both potent and selective phosphodiesterase 10A (PDE10A) inhibitors. For in vitro characterization, inhibition of PDE10A mediated cAMP hydrolysis was used and a QSA ...

    Novel imidazo[1,5-a]pyrido[3,2-e]pyrazines have been synthesized and characterized as both potent and selective phosphodiesterase 10A (PDE10A) inhibitors. For in vitro characterization, inhibition of PDE10A mediated cAMP hydrolysis was used and a QSAR model was established to analyze substitution effects. The outcome of this analysis was complemented by the crystal structure of PDE10A in complex with compound 49. Qualitatively new interactions between inhibitor and binding site were found, contrasting with previously published crystal structures of papaverine-like inhibitors. In accordance with the known antipsychotic potential of PDE10A inhibitors, MK-801 induced stereotypy and hyperactivity in rats were reversed by selected compounds. Thus, a promising compound class has been identified for the treatment of schizophrenia that could circumvent side effects connected with current therapies.


    Organizational Affiliation

    Biotie Therapies GmbH, Meissner Strasse 191, 01445 Radebeul, Germany. norbert.hoefgen@biotie.com




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
cAMP and cAMP-inhibited cGMP 3',5'-cyclic phosphodiesterase 10A
A
308Rattus norvegicusMutation(s): 0
Gene Names: Pde10a
EC: 3.1.4.17, 3.1.4.35
Find proteins for Q9QYJ6 (Rattus norvegicus)
Go to UniProtKB:  Q9QYJ6
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download SDF File
Download CCD File
A
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
MG
Query on MG

Download SDF File
Download CCD File
A
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
Z73
Query on Z73

Download SDF File
Download CCD File
A
2-methoxy-6,7-dimethyl-9-propylimidazo[1,5-a]pyrido[3,2-e]pyrazine
C15 H18 N4 O
YNADXFWEXJTQSZ-UHFFFAOYSA-N
 Ligand Interaction
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
Z73IC50: 7 - 32 nM (96) BINDINGDB
Z73IC50: 7.28 nM BINDINGMOAD
Z73IC50: 7.28 nM PDBBIND
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.3 Å
  • R-Value Free: 0.229
  • R-Value Work: 0.176
  • Space Group: H 3
Unit Cell:
Length (Å)Angle (°)
a = 120.149α = 90.00
b = 120.149β = 90.00
c = 83.119γ = 120.00
Software Package:
Software NamePurpose
MOSFLMdata reduction
REFMACrefinement
SCALAdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2010-05-19
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
