3HSM

Crystal structure of distal N-terminal beta-trefoil domain of Ryanodine Receptor type 1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free: 0.276
  • R-Value Work: 0.229

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Crystal structure of type I ryanodine receptor amino-terminal beta-trefoil domain reveals a disease-associated mutation "hot spot" loop

Amador, F.J.Liu, S.Ishiyama, N.Plevin, M.J.Wilson, A.MacLennan, D.H.Ikura, M.

(2009) Proc Natl Acad Sci U S A 106: 11040-11044

  • DOI: 10.1073/pnas.0905186106
  • Primary Citation of Related Structures:
    3HSM

  • PubMed Abstract:
  • Muscle contraction and relaxation is regulated by transient elevations of myoplasmic Ca(2+). Ca(2+) is released from stores in the lumen of the sarco(endo)plasmic reticulum (SER) to initiate formation of the Ca(2+) transient by activation of a class of Ca(2+) release channels referred to as ryanodine receptors (RyRs) and is pumped back into the SER lumen by Ca(2+)-ATPases (SERCAs) to terminate the Ca(2+) transient ...

    Muscle contraction and relaxation is regulated by transient elevations of myoplasmic Ca(2+). Ca(2+) is released from stores in the lumen of the sarco(endo)plasmic reticulum (SER) to initiate formation of the Ca(2+) transient by activation of a class of Ca(2+) release channels referred to as ryanodine receptors (RyRs) and is pumped back into the SER lumen by Ca(2+)-ATPases (SERCAs) to terminate the Ca(2+) transient. Mutations in the type 1 ryanodine receptor gene, RYR1, are associated with 2 skeletal muscle disorders, malignant hyperthermia (MH), and central core disease (CCD). The evaluation of proposed mechanisms by which RyR1 mutations cause MH and CCD is hindered by the lack of high-resolution structural information. Here, we report the crystal structure of the N-terminal 210 residues of RyR1 (RyR(NTD)) at 2.5 A. The RyR(NTD) structure is similar to that of the suppressor domain of type 1 inositol 1,4,5-trisphosphate receptor (IP(3)Rsup), but lacks most of the long helix-turn-helix segment of the "arm" domain in IP(3)Rsup. The N-terminal beta-trefoil fold, found in both RyR and IP(3)R, is likely to play a critical role in regulatory mechanisms in this channel family. A disease-associated mutation "hot spot" loop was identified between strands 8 and 9 in a highly basic region of RyR1. Biophysical studies showed that 3 MH-associated mutations (C36R, R164C, and R178C) do not adversely affect the global stability or fold of RyR(NTD), supporting previously described mechanisms whereby mutations perturb protein-protein interactions.


    Organizational Affiliation

    Division of Signaling Biology, Ontario Cancer Institute and Department of Medical Biophysics, University of Toronto, 101 College Street, Toronto, ON, Canada M5G 1L7.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Ryanodine receptor 1A, B213Oryctolagus cuniculusMutation(s): 0
Gene Names: RYR1
UniProt
Find proteins for P11716 (Oryctolagus cuniculus)
Explore P11716
Go to UniProtKB:  P11716
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free: 0.276
  • R-Value Work: 0.229
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 140.597α = 90
b = 35.299β = 99.37
c = 78.94γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
CNSrefinement
PDB_EXTRACTdata extraction
HKL-3000data collection
HKL-3000data reduction
CNSphasing

Structure Validation

View Full Validation Report




Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-07-28
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2017-11-01
    Changes: Advisory, Refinement description
