3BW9

Crystal Structure of HLA B*3508 in complex with a HCMV 12-mer peptide from the pp65 protein


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.75 Å
  • R-Value Free: 0.235
  • R-Value Work: 0.189
  • R-Value Observed: 0.192

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Impact of clonal competition for peptide-MHC complexes on the CD8+ T-cell repertoire selection in a persistent viral infection

Wynn, K.K.Fulton, Z.Cooper, L.Silins, S.L.Gras, S.Archbold, J.K.Tynan, F.E.Miles, J.J.McCluskey, J.Burrows, S.R.Rossjohn, J.Khanna, R.

(2008) Blood 111: 4283-4292

  • DOI: 10.1182/blood-2007-11-122622
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • CD8(+) T-cell responses to persistent viral infections are characterized by the accumulation of an oligoclonal T-cell repertoire and a reduction in the naive T-cell pool. However, the precise mechanism for this phenomenon remains elusive. Here we sho ...

    CD8(+) T-cell responses to persistent viral infections are characterized by the accumulation of an oligoclonal T-cell repertoire and a reduction in the naive T-cell pool. However, the precise mechanism for this phenomenon remains elusive. Here we show that human cytomegalovirus (HCMV)-specific CD8(+) T cells recognizing distinct epitopes from the pp65 protein and restricted through an identical HLA class I allele (HLA B*3508) exhibited either a highly conserved public T-cell repertoire or a private, diverse T-cell response, which was uniquely altered in each donor following in vitro antigen exposure. Selection of a public T-cell receptor (TCR) was coincident with an atypical major histocompatibility complex (MHC)-peptide structure, in that the epitope adopted a helical conformation that bulged from the peptide-binding groove, while a diverse TCR profile was observed in response to the epitope that formed a flatter, more "featureless" landscape. Clonotypes with biased TCR usage demonstrated more efficient recognition of virus-infected cells, a greater CD8 dependency, and were more terminally differentiated in their phenotype when compared with the T cells expressing diverse TCR. These findings provide new insights into our understanding on how the biology of antigen presentation in addition to the structural features of the pMHC-I might shape the T-cell repertoire and its phenotype.


    Organizational Affiliation

    Australian Centre for Vaccine Development and Division of Infectious Diseases and Immunology, Queensland Institute of Medical Research, Brisbane, Australia.



Macromolecules
  • Find similar proteins by: Sequence   |   Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
CPS peptide from 65 kDa lower matrix phosphoprotein
C
12N/AMutation(s): 0
Find proteins for P18139 (Human cytomegalovirus (strain Towne))
Go to UniProtKB:  P18139
Protein Feature View
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
HLA class I histocompatibility antigen, B-35 alpha chain
A
276Homo sapiensMutation(s): 0
Gene Names: HLA-BHLAB
Find proteins for P01889 (Homo sapiens)
Go to UniProtKB:  P01889
NIH Common Fund Data Resources
PHAROS  P01889
Protein Feature View
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Beta-2-microglobulin
B
100Homo sapiensMutation(s): 0
Gene Names: B2MCDABP0092HDCMA22P
Find proteins for P61769 (Homo sapiens)
Go to UniProtKB:  P61769
NIH Common Fund Data Resources
PHAROS  P61769
Protein Feature View
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.75 Å
  • R-Value Free: 0.235
  • R-Value Work: 0.189
  • R-Value Observed: 0.192
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 51.006α = 90
b = 82.086β = 90
c = 111.515γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
PHASERphasing
REFMACrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2008-04-22
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2017-10-25
    Changes: Refinement description
