3AS2

Crystal Structure Analysis of Chitinase A from Vibrio harveyi with novel inhibitors - W275G mutant complex structure with Propentofylline


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.8 Å
  • R-Value Free: 0.193
  • R-Value Work: 0.147

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Potent family-18 chitinase inhibitors: x-ray structures, affinities, and binding mechanisms

Pantoom, S.Vetter, I.R.Prinz, H.Suginta, W.

(2011) J.Biol.Chem. 286: 24312-24323

  • DOI: 10.1074/jbc.M110.183376
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Six novel inhibitors of Vibrio harveyi chitinase A (VhChiA), a family-18 chitinase homolog, were identified by in vitro screening of a library of pharmacologically active compounds. Unlike the previously identified inhibitors that mimicked the reacti ...

    Six novel inhibitors of Vibrio harveyi chitinase A (VhChiA), a family-18 chitinase homolog, were identified by in vitro screening of a library of pharmacologically active compounds. Unlike the previously identified inhibitors that mimicked the reaction intermediates, crystallographic evidence from 14 VhChiA-inhibitor complexes showed that all of the inhibitor molecules occupied the outer part of the substrate-binding cleft at two hydrophobic areas. The interactions at the aglycone location are well defined and tightly associated with Trp-397 and Trp-275, whereas the interactions at the glycone location are patchy, indicating lower affinity and a loose interaction with two consensus residues, Trp-168 and Val-205. When Trp-275 was substituted with glycine (W275G), the binding affinity toward all of the inhibitors dramatically decreased, and in most structures two inhibitor molecules were found to stack against Trp-397 at the aglycone site. Such results indicate that hydrophobic interactions are important for binding of the newly identified inhibitors by the chitinase. X-ray data and isothermal microcalorimetry showed that the inhibitors occupied the active site of VhChiA in three different binding modes, including single-site binding, independent two-site binding, and sequential two-site binding. The inhibitory effect of dequalinium in the low nanomolar range makes this compound an extremely attractive lead compound for plausible development of therapeutics against human diseases involving chitinase-mediated pathologies.


    Related Citations:
    • Crystal structures of Vibrio harveyi chitinase A complexed with chitooligosaccharides: implications for the catalytic mechanism
      Songsiriritthigul, C.,Pantoom, S.,Aguda, A.H.,Robinson, R.C.,Suginta, W.
      (2008) J.Struct.Biol. 162: 491


    Organizational Affiliation

    Biochemistry-Electrochemistry Research Unit, School of Chemistry, Institute of Science, Suranaree University of Technology, Nakhon Ratchasima 30000, Thailand.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Chitinase A
A
584Vibrio harveyiMutation(s): 1
Gene Names: chiA
Find proteins for Q9AMP1 (Vibrio harveyi)
Go to UniProtKB:  Q9AMP1
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
POY
Query on POY

Download SDF File
Download CCD File
A
3-methyl-1-(5-oxohexyl)-7-propyl-3,7-dihydro-1H-purine-2,6-dione
Propentofylline
C15 H22 N4 O3
RBQOQRRFDPXAGN-UHFFFAOYSA-N
 Ligand Interaction
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
POYIC50: 360000 nM PDBBIND
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.8 Å
  • R-Value Free: 0.193
  • R-Value Work: 0.147
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 66.290α = 90.00
b = 84.050β = 90.00
c = 102.310γ = 90.00
Software Package:
Software NamePurpose
XSCALEdata scaling
REFMACrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2011-04-20
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
  • Version 1.2: 2014-01-29
    Type: Database references
