3AOI

RNA polymerase-Gfh1 complex (Crystal type 2)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.30 Å
  • R-Value Free: 0.338
  • R-Value Work: 0.317
  • R-Value Observed: 0.317

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Crystal structure of bacterial RNA polymerase bound with a transcription inhibitor protein

Tagami, S.Sekine, S.I.Kumarevel, T.Hino, N.Murayama, Y.Kamegamori, S.Yamamoto, M.Sakamoto, K.Yokoyama, S.

(2010) Nature 468: 978-982

  • DOI: 10.1038/nature09573
  • Primary Citation of Related Structures:
    3AOH, 3AOI

  • PubMed Abstract:
  • The multi-subunit DNA-dependent RNA polymerase (RNAP) is the principal enzyme of transcription for gene expression. Transcription is regulated by various transcription factors. Gre factor homologue 1 (Gfh1), found in the Thermus genus, is a close homologue of the well-conserved bacterial transcription factor GreA, and inhibits transcription initiation and elongation by binding directly to RNAP ...

    The multi-subunit DNA-dependent RNA polymerase (RNAP) is the principal enzyme of transcription for gene expression. Transcription is regulated by various transcription factors. Gre factor homologue 1 (Gfh1), found in the Thermus genus, is a close homologue of the well-conserved bacterial transcription factor GreA, and inhibits transcription initiation and elongation by binding directly to RNAP. The structural basis of transcription inhibition by Gfh1 has remained elusive, although the crystal structures of RNAP and Gfh1 have been determined separately. Here we report the crystal structure of Thermus thermophilus RNAP complexed with Gfh1. The amino-terminal coiled-coil domain of Gfh1 fully occludes the channel formed between the two central modules of RNAP; this channel would normally be used for nucleotide triphosphate (NTP) entry into the catalytic site. Furthermore, the tip of the coiled-coil domain occupies the NTP β-γ phosphate-binding site. The NTP-entry channel is expanded, because the central modules are 'ratcheted' relative to each other by ∼7°, as compared with the previously reported elongation complexes. This 'ratcheted state' is an alternative structural state, defined by a newly acquired contact between the central modules. Therefore, the shape of Gfh1 is appropriate to maintain RNAP in the ratcheted state. Simultaneously, the ratcheting expands the nucleic-acid-binding channel, and kinks the bridge helix, which connects the central modules. Taken together, the present results reveal that Gfh1 inhibits transcription by preventing NTP binding and freezing RNAP in the alternative structural state. The ratcheted state might also be associated with other aspects of transcription, such as RNAP translocation and transcription termination.


    Organizational Affiliation

    Department of Biophysics and Biochemistry, Graduate School of Science, University of Tokyo, 7-3-1 Hongo, Bunkyo-ku, Tokyo 113-0033, Japan.



Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit alpha
A, B, F, G, K, L
A, B, F, G, K, L
315Thermus thermophilus HB8Mutation(s): 0
Gene Names: rpoATTHA1664
EC: 2.7.7.6
UniProt
Find proteins for Q5SHR6 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q5SHR6
Go to UniProtKB:  Q5SHR6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5SHR6
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit betaC, H, M1119Thermus thermophilus HB8Mutation(s): 0
Gene Names: rpoBTTHA1813
EC: 2.7.7.6
UniProt
Find proteins for Q8RQE9 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q8RQE9
Go to UniProtKB:  Q8RQE9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8RQE9
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit beta'D, I, N1524Thermus thermophilus HB8Mutation(s): 0
Gene Names: rpoCTTHA1812
EC: 2.7.7.6
UniProt
Find proteins for Q8RQE8 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q8RQE8
Go to UniProtKB:  Q8RQE8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8RQE8
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit omegaE, J, O99Thermus thermophilus HB8Mutation(s): 0
Gene Names: rpoZTTHA1561
EC: 2.7.7.6
UniProt
Find proteins for Q8RQE7 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q8RQE7
Go to UniProtKB:  Q8RQE7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8RQE7
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChainsSequence LengthOrganismDetailsImage
Anti-cleavage anti-GreA transcription factor Gfh1V [auth X],
W [auth Y],
X [auth Z]
156Thermus thermophilus HB8Mutation(s): 0
Gene Names: TTHA1042gfh1
UniProt
Find proteins for Q5SJG6 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q5SJG6
Go to UniProtKB:  Q5SJG6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5SJG6
Protein Feature View
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChainsLengthOrganismImage
DNA (5'-D(*GP*GP*TP*CP*TP*GP*TP*AP*TP*CP*AP*CP*GP*AP*GP*CP*CP*A*CP*CP*GP*CP*CP*GP*CP*AP*T)-3')P, R, T 27N/A
Protein Feature View
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChainsLengthOrganismImage
RNA (5'-R(*CP*CP*CP*GP*GP*AP*AP*GP*AP*UP*CP*AP*UP*CP*UP*UP*CP*CP*GP*GP*GP*GP*GP*AP*U*GP*CP*GP*GP*CP*GP*G)-3')Q, S, U 32N/A
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.30 Å
  • R-Value Free: 0.338
  • R-Value Work: 0.317
  • R-Value Observed: 0.317
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 189.23α = 90
b = 264.51β = 116.68
c = 193.93γ = 90
Software Package:
Software NamePurpose
PHASERphasing
CNSrefinement
XDSdata reduction
XDSdata scaling

Structure Validation

View Full Validation Report




Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2010-12-08
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
