2Q2H

Crystal structure of the protein secretion chaperone CsaA from Agrobacterium tumefaciens with a genetically fused phage-display derived peptide substrate at the N-terminus.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.65 Å
  • R-Value Free: 0.173
  • R-Value Work: 0.160
  • R-Value Observed: 0.161

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Phage display and crystallographic analysis reveals potential substrate/binding site interactions in the protein secretion chaperone CsaA from Agrobacterium tumefaciens.

Feldman, A.R.Shapova, Y.A.Wu, S.S.Oliver, D.C.Heller, M.McIntosh, L.P.Scott, J.K.Paetzel, M.

(2008) J Mol Biol 379: 457-470

  • DOI: 10.1016/j.jmb.2008.03.048
  • Primary Citation of Related Structures:
    2Q2H, 2Q2I

  • PubMed Abstract:
  • The protein CsaA has been proposed to function as a protein secretion chaperone in bacteria that lack the Sec-dependent protein-targeting chaperone SecB. CsaA is a homodimer with two putative substrate-binding pockets, one in each monomer. To test the hypothesis that these cavities are indeed substrate-binding sites able to interact with other polypeptide chains, we selected a peptide that bound to CsaA from a random peptide library displayed on phage ...

    The protein CsaA has been proposed to function as a protein secretion chaperone in bacteria that lack the Sec-dependent protein-targeting chaperone SecB. CsaA is a homodimer with two putative substrate-binding pockets, one in each monomer. To test the hypothesis that these cavities are indeed substrate-binding sites able to interact with other polypeptide chains, we selected a peptide that bound to CsaA from a random peptide library displayed on phage. Presented here is the structure of CsaA from Agrobacterium tumefaciens (AtCsaA) solved in the presence and absence of the selected peptide. To promote co-crystallization, the sequence for this peptide was genetically fused to the amino-terminus of AtCsaA. The resulting 1.65 A resolution crystal structure reveals that the tethered peptide from one AtCsaA molecule binds to the proposed substrate-binding pocket of a symmetry-related molecule possibly mimicking the interaction between a pre-protein substrate and CsaA. The structure shows that the peptide lies in an extended conformation with alanine, proline and glutamine side chains pointing into the binding pocket. The peptide interacts with the atoms of the AtCsaA-binding pocket via seven direct hydrogen bonds. The side chain of a conserved pocket residue, Arg76, has an "up" conformation when the CsaA-binding site is empty and a "down" conformation when the CsaA-binding site is occupied, suggesting that this residue may function to stabilize the peptide in the binding cavity. The presented aggregation assays, phage-display analysis and structural analysis are consistent with AtCsaA being a general chaperone. The properties of the proposed CsaA-binding pocket/peptide interactions are compared to those from other structurally characterized molecular chaperones.


    Organizational Affiliation

    Department of Molecular Biology and Biochemistry, Simon Fraser University, South Science Building, 8888 University Drive, Burnaby, British Columbia, Canada.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Secretion chaperone, phage-display derived peptideA, B131Agrobacterium fabrum str. C58Mutation(s): 0
Gene Names: csaAAtu2208
UniProt
Find proteins for A9CI62 (Agrobacterium fabrum (strain C58 / ATCC 33970))
Explore A9CI62
Go to UniProtKB:  A9CI62
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CIT
Query on CIT

Download Ideal Coordinates CCD File
C [auth A]CITRIC ACID
C6 H8 O7
KRKNYBCHXYNGOX-UHFFFAOYSA-N
 Ligand Interaction
ACT
Query on ACT

Download Ideal Coordinates CCD File
D [auth B], E [auth B]ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.65 Å
  • R-Value Free: 0.173
  • R-Value Work: 0.160
  • R-Value Observed: 0.161
  • Space Group: P 61
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 60.528α = 90
b = 60.528β = 90
c = 115.247γ = 120
Software Package:
Software NamePurpose
d*TREKdata scaling
REFMACrefinement
PDB_EXTRACTdata extraction
CrystalCleardata collection
CrystalCleardata reduction
PHASERphasing

Structure Validation

View Full Validation Report




Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2008-04-01
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Advisory, Derived calculations, Refinement description, Version format compliance
