2Q2I

Crystal structure of the protein secretion chaperone CsaA from Agrobacterium tumefaciens.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.55 Å
  • R-Value Free: 0.208
  • R-Value Work: 0.178

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Phage display and crystallographic analysis reveals potential substrate/binding site interactions in the protein secretion chaperone CsaA from Agrobacterium tumefaciens.

Feldman, A.R.Shapova, Y.A.Wu, S.S.Oliver, D.C.Heller, M.McIntosh, L.P.Scott, J.K.Paetzel, M.

(2008) J.Mol.Biol. 379: 457-470

  • DOI: 10.1016/j.jmb.2008.03.048
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The protein CsaA has been proposed to function as a protein secretion chaperone in bacteria that lack the Sec-dependent protein-targeting chaperone SecB. CsaA is a homodimer with two putative substrate-binding pockets, one in each monomer. To test th ...

    The protein CsaA has been proposed to function as a protein secretion chaperone in bacteria that lack the Sec-dependent protein-targeting chaperone SecB. CsaA is a homodimer with two putative substrate-binding pockets, one in each monomer. To test the hypothesis that these cavities are indeed substrate-binding sites able to interact with other polypeptide chains, we selected a peptide that bound to CsaA from a random peptide library displayed on phage. Presented here is the structure of CsaA from Agrobacterium tumefaciens (AtCsaA) solved in the presence and absence of the selected peptide. To promote co-crystallization, the sequence for this peptide was genetically fused to the amino-terminus of AtCsaA. The resulting 1.65 A resolution crystal structure reveals that the tethered peptide from one AtCsaA molecule binds to the proposed substrate-binding pocket of a symmetry-related molecule possibly mimicking the interaction between a pre-protein substrate and CsaA. The structure shows that the peptide lies in an extended conformation with alanine, proline and glutamine side chains pointing into the binding pocket. The peptide interacts with the atoms of the AtCsaA-binding pocket via seven direct hydrogen bonds. The side chain of a conserved pocket residue, Arg76, has an "up" conformation when the CsaA-binding site is empty and a "down" conformation when the CsaA-binding site is occupied, suggesting that this residue may function to stabilize the peptide in the binding cavity. The presented aggregation assays, phage-display analysis and structural analysis are consistent with AtCsaA being a general chaperone. The properties of the proposed CsaA-binding pocket/peptide interactions are compared to those from other structurally characterized molecular chaperones.


    Organizational Affiliation

    Department of Molecular Biology and Biochemistry, Simon Fraser University, South Science Building, 8888 University Drive, Burnaby, British Columbia, Canada.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Secretion chaperone
A, B
116Agrobacterium fabrum (strain C58 / ATCC 33970)Mutation(s): 0
Gene Names: csaA
Find proteins for A9CI62 (Agrobacterium fabrum (strain C58 / ATCC 33970))
Go to UniProtKB:  A9CI62
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
EDO
Query on EDO

Download SDF File
Download CCD File
A, B
1,2-ETHANEDIOL
ETHYLENE GLYCOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.55 Å
  • R-Value Free: 0.208
  • R-Value Work: 0.178
  • Space Group: P 61
Unit Cell:
Length (Å)Angle (°)
a = 60.653α = 90.00
b = 60.653β = 90.00
c = 113.389γ = 120.00
Software Package:
Software NamePurpose
d*TREKdata scaling
PDB_EXTRACTdata extraction
REFMACrefinement
CrystalCleardata collection
CrystalCleardata reduction
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2008-04-01
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Advisory, Derived calculations, Version format compliance
