2H7F

Structure of variola topoisomerase covalently bound to DNA

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free: 0.237
  • R-Value Work: 0.191
  • R-Value Observed: 0.193

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history.


Literature

Structural basis for specificity in the poxvirus topoisomerase.

Perry, K., Hwang, Y., Bushman, F.D., Van Duyne, G.D.

(2006) Mol Cell 23: 343-354

  • DOI: 10.1016/j.molcel.2006.06.015
  • Primary Citation of Related Structures:
    2H7F, 2H7G

  • PubMed Abstract:

    • Although smallpox has been eradicated from the human population, it is presently feared as a possible agent of bioterrorism. The smallpox virus codes for its own topoisomerase enzyme that differs from its cellular counterpart by requiring a specific DNA sequence for activation of catalysis ...

    Although smallpox has been eradicated from the human population, it is presently feared as a possible agent of bioterrorism. The smallpox virus codes for its own topoisomerase enzyme that differs from its cellular counterpart by requiring a specific DNA sequence for activation of catalysis. Here we present crystal structures of the smallpox virus topoisomerase enzyme bound both covalently and noncovalently to a specific DNA sequence. These structures reveal the basis for site-specific DNA recognition, and they explain how catalysis is likely activated by formation of a specific enzyme-DNA interface. Unexpectedly, the poxvirus enzyme uses a major groove binding alpha helix that is not present in the human enzyme to recognize part of the core recognition sequence and activate the enzyme for catalysis. The topoisomerase-DNA complex structures also provide a three-dimensional framework that may facilitate the rational design of therapeutic agents to treat poxvirus infections.

    Organizational Affiliation:

    University of Pennsylvania School of Medicine, Department of Biochemistry and Biophysics and Howard Hughes Medical Institute, Philadelphia, Pennsylvania 19104, USA.



Macromolecules

Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
DNA topoisomerase 1C [auth X]314Variola virusMutation(s): 3
Gene Names: TOP1
EC: 5.99.1.2 (PDB Primary Data), 5.6.2.1 (UniProt)
UniProt
Find proteins for P32989 (Variola virus (isolate Human/India/Ind3/1967))
Explore P32989
Go to UniProtKB:  P32989
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP32989
Protein Feature View
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 1
MoleculeChainsLengthOrganismImage
5'-D(*TP*TP*GP*TP*CP*GP*CP*CP*CP*TP*T)-3'A [auth Y]11N/A
Protein Feature View
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChainsLengthOrganismImage
5'-D(*TP*AP*AP*TP*AP*AP*GP*GP*GP*CP*GP*AP*CP*A)-3'B [auth Z]14N/A
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
PTR
Query on PTR		C [auth X]L-PEPTIDE LINKINGC9 H12 N O6 PTYR
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free: 0.237
  • R-Value Work: 0.191
  • R-Value Observed: 0.193
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 68.523α = 90
b = 138.232β = 90
c = 113.079γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
SOLVEphasing
REFMACrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



View more in-depth experimental data

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2006-08-15
    Type: Initial release
  • Version 1.1: 2008-05-01
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Advisory, Refinement description, Version format compliance
  • Version 1.3: 2017-10-18
    Changes: Refinement description
  • Version 1.4: 2021-10-20
    Changes: Database references, Derived calculations
