2FKG

The Crystal Structure of Engineered OspA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.4 Å
  • R-Value Free: 0.255
  • R-Value Work: 0.219

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Atomic structures of peptide self-assembly mimics.

Makabe, K.McElheny, D.Tereshko, V.Hilyard, A.Gawlak, G.Yan, S.Koide, A.Koide, S.

(2006) Proc.Natl.Acad.Sci.Usa 103: 17753-17758

  • DOI: 10.1073/pnas.0606690103
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Although the beta-rich self-assemblies are a major structural class for polypeptides and the focus of intense research, little is known about their atomic structures and dynamics due to their insoluble and noncrystalline nature. We developed a protei ...

    Although the beta-rich self-assemblies are a major structural class for polypeptides and the focus of intense research, little is known about their atomic structures and dynamics due to their insoluble and noncrystalline nature. We developed a protein engineering strategy that captures a self-assembly segment in a water-soluble molecule. A predefined number of self-assembling peptide units are linked, and the beta-sheet ends are capped to prevent aggregation, which yields a mono-dispersed soluble protein. We tested this strategy by using Borrelia outer surface protein (OspA) whose single-layer beta-sheet located between two globular domains consists of two beta-hairpin units and thus can be considered as a prototype of self-assembly. We constructed self-assembly mimics of different sizes and determined their atomic structures using x-ray crystallography and NMR spectroscopy. Highly regular beta-sheet geometries were maintained in these structures, and peptide units had a nearly identical conformation, supporting the concept that a peptide in the regular beta-geometry is primed for self-assembly. However, we found small but significant differences in the relative orientation between adjacent peptide units in terms of beta-sheet twist and bend, suggesting their inherent flexibility. Modeling shows how this conformational diversity, when propagated over a large number of peptide units, can lead to a substantial degree of nanoscale polymorphism of self-assemblies.


    Organizational Affiliation

    Department of Biochemistry and Molecular Biology, University of Chicago, Chicago, IL 60637, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Outer Surface Protein A
A
320Borrelia burgdorferi (strain ATCC 35210 / B31 / CIP 102532 / DSM 4680)Mutation(s): 0
Gene Names: ospA
Find proteins for P0CL66 (Borrelia burgdorferi (strain ATCC 35210 / B31 / CIP 102532 / DSM 4680))
Go to UniProtKB:  P0CL66
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.4 Å
  • R-Value Free: 0.255
  • R-Value Work: 0.219
  • Space Group: C 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 99.447α = 90.00
b = 76.894β = 120.00
c = 51.941γ = 90.00
Software Package:
Software NamePurpose
HKL-2000data reduction
REFMACrefinement
SCALEPACKdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2006-11-21
    Type: Initial release
  • Version 1.1: 2008-05-01
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Advisory, Version format compliance
