2V3X

His243Ala Escherichia coli aminopeptidase P in complex with substrate


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.7 Å
  • R-Value Free: 0.154
  • R-Value Work: 0.141

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Complexes of Mutants of Escherichia Coli Aminopeptidase P and the Tripeptide Substrate Valproleu.

Graham, S.C.Guss, J.M.

(2008) Arch.Biochem.Biophys. 469: 200

  • DOI: 10.1016/j.abb.2007.10.009
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Aminopeptidase P (APPro) is a manganese-containing enzyme that catalyses the hydrolysis of the N-terminal residue of a polypeptide if the second residue is proline. Structures of APPro mutants with reduced or negligible activity have been determined ...

    Aminopeptidase P (APPro) is a manganese-containing enzyme that catalyses the hydrolysis of the N-terminal residue of a polypeptide if the second residue is proline. Structures of APPro mutants with reduced or negligible activity have been determined in complex with the tripeptide substrate ValProLeu. In the complex of Glu383Ala APPro with ValProLeu one of the two metal sites is only partly occupied, indicating an essential role for Glu383 in metal binding in the presence of substrate. His361Ala APPro clearly possesses residual activity as the ValProLeu substrate has been cleaved in the crystals; difference electron density consistent with bound ProLeu dipeptide and a disordered Val amino acid is present at the active site. Contrary to previous suggestions, the His243Ala mutant is capable of binding substrate. The structure of the His243Ala APPro complex with ValProLeu shows that the peptide interacts with one of the active-site metal atoms via its terminal amino group. The implications of these complexes for the roles of the respective residues in APPro catalysis are discussed.


    Organizational Affiliation

    Division of Structural Biology, The Wellcome Trust Centre for Human Genetics, University of Oxford, Oxford, OX3 7BN, UK.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
XAA-PRO AMINOPEPTIDASE
A
440Escherichia coli (strain K12)Mutation(s): 1
Gene Names: pepP
EC: 3.4.11.9
Find proteins for P15034 (Escherichia coli (strain K12))
Go to UniProtKB:  P15034
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
TRIPEPTIDE (VALINE-PROLINE-LEUCINE)
B
3N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
MN
Query on MN

Download SDF File
Download CCD File
A
MANGANESE (II) ION
Mn
WAEMQWOKJMHJLA-UHFFFAOYSA-N
 Ligand Interaction
CL
Query on CL

Download SDF File
Download CCD File
A
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
CSO
Query on CSO
A
L-PEPTIDE LINKINGC3 H7 N O3 SCYS
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.7 Å
  • R-Value Free: 0.154
  • R-Value Work: 0.141
  • Space Group: P 64 2 2
Unit Cell:
Length (Å)Angle (°)
a = 177.396α = 90.00
b = 177.396β = 90.00
c = 96.499γ = 120.00
Software Package:
Software NamePurpose
DENZOdata reduction
REFMACphasing
SCALEPACKdata scaling
REFMACrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2007-11-20
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Advisory, Version format compliance
  • Version 1.2: 2019-03-06
    Type: Data collection, Derived calculations, Experimental preparation, Other
