2QI1

Crystal structure of protease inhibitor, MIT-1-KK81 in complex with wild type HIV-1 protease


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.205
  • R-Value Work: 0.156
  • R-Value Observed: 0.159

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

HIV-1 protease inhibitors from inverse design in the substrate envelope exhibit subnanomolar binding to drug-resistant variants.

Altman, M.D.Ali, A.Reddy, G.S.Nalam, M.N.Anjum, S.G.Cao, H.Chellappan, S.Kairys, V.Fernandes, M.X.Gilson, M.K.Schiffer, C.A.Rana, T.M.Tidor, B.

(2008) J Am Chem Soc 130: 6099-6113

  • DOI: 10.1021/ja076558p
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • The acquisition of drug-resistant mutations by infectious pathogens remains a pressing health concern, and the development of strategies to combat this threat is a priority. Here we have applied a general strategy, inverse design using the substrate ...

    The acquisition of drug-resistant mutations by infectious pathogens remains a pressing health concern, and the development of strategies to combat this threat is a priority. Here we have applied a general strategy, inverse design using the substrate envelope, to develop inhibitors of HIV-1 protease. Structure-based computation was used to design inhibitors predicted to stay within a consensus substrate volume in the binding site. Two rounds of design, synthesis, experimental testing, and structural analysis were carried out, resulting in a total of 51 compounds. Improvements in design methodology led to a roughly 1000-fold affinity enhancement to a wild-type protease for the best binders, from a Ki of 30-50 nM in round one to below 100 pM in round two. Crystal structures of a subset of complexes revealed a binding mode similar to each design that respected the substrate envelope in nearly all cases. All four best binders from round one exhibited broad specificity against a clinically relevant panel of drug-resistant HIV-1 protease variants, losing no more than 6-13-fold affinity relative to wild type. Testing a subset of second-round compounds against the panel of resistant variants revealed three classes of inhibitors: robust binders (maximum affinity loss of 14-16-fold), moderate binders (35-80-fold), and susceptible binders (greater than 100-fold). Although for especially high-affinity inhibitors additional factors may also be important, overall, these results suggest that designing inhibitors using the substrate envelope may be a useful strategy in the development of therapeutics with low susceptibility to resistance.


    Organizational Affiliation

    Department of Chemistry, Massachusetts Institute of Technology, Cambridge, Massachusetts 02139, USA.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Protease
A, B
99Human immunodeficiency virus 1Mutation(s): 1
Gene Names: pol
Find proteins for O38732 (Human immunodeficiency virus 1)
Go to UniProtKB:  O38732
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
MZ4
Query on MZ4

Download CCD File
A
N-[(1S,2R)-1-BENZYL-2-HYDROXY-3-{[(3-METHOXYPHENYL)SULFONYL](2-THIENYLMETHYL)AMINO}PROPYL]-3,4-DIHYDROXYBENZAMIDE
C29 H30 N2 O7 S2
VEWOLYUNGFMYJI-LBNVMWSVSA-N
 Ligand Interaction
PO4
Query on PO4

Download CCD File
A, B
PHOSPHATE ION
O4 P
NBIIXXVUZAFLBC-UHFFFAOYSA-K
 Ligand Interaction
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
MZ4Ki:  50   nM  Binding MOAD
MZ4Ki:  50   nM  PDBBind
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.205
  • R-Value Work: 0.156
  • R-Value Observed: 0.159
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 50.777α = 90
b = 58.029β = 90
c = 61.779γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
SCALEPACKdata scaling
AMoREphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2008-04-22
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Advisory, Derived calculations, Refinement description, Version format compliance
  • Version 1.2: 2017-10-18
    Changes: Refinement description
