2PPV | pdb_00002ppv

CRYSTAL STRUCTURE OF a protein belonging to the UPF0052 (SE_0549) FROM STAPHYLOCOCCUS EPIDERMIDIS ATCC 12228 AT 2.00 A RESOLUTION

• PDB DOI: https://doi.org/10.2210/pdb2PPV/pdb

• Classification: TRANSFERASE
• Organism(s): Staphylococcus epidermidis ATCC 12228
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2007-04-30 Released: 2007-05-15
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:
  0.212 (Depositor), 0.220 (DCC)
• R-Value Work:
  0.171 (Depositor), 0.180 (DCC)
• R-Value Observed:
  0.173 (Depositor)

Literature

Crystal structure of uncharacterized protein (NP_764104.1) from Staphylococcus epidermidis ATCC 12228 at 2.00 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA,PQS (software)

Macromolecule Content

• Total Structure Weight: 36.79 kDa
• Atom Count: 2,771
• Modeled Residue Count: 325
• Deposited Residue Count: 332
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized protein	A	332	Staphylococcus epidermidis ATCC 12228	Mutation(s): 8  Gene Names: NP_764104.1, SE_0549
UniProt
Find proteins for A0A0H2VHQ6 (Staphylococcus epidermidis (strain ATCC 12228 / FDA PCI 1200)) Explore A0A0H2VHQ6  Go to UniProtKB:  A0A0H2VHQ6

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PO4	B [auth A]	PHOSPHATE ION O4 P NBIIXXVUZAFLBC-UHFFFAOYSA-K

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:  0.212 (Depositor), 0.220 (DCC)
• R-Value Work:  0.171 (Depositor), 0.180 (DCC)
• R-Value Observed: 0.173 (Depositor)

Diffraction Data: https://doi.org/10.18430/M32PPV

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 136.666	α = 90
b = 136.814	β = 90
c = 55.957	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
SOLVE	phasing
REFMAC	refinement
SCALA	data scaling
PDB_EXTRACT	data extraction
MAR345	data collection
MOSFLM	data reduction
CCP4	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2007-05-15
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2007-05-15
  Type: Initial release

• Version 1.1: 2008-05-01
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Advisory, Derived calculations, Source and taxonomy, Version format compliance
• Version 1.3: 2017-10-18
  Changes: Refinement description
• Version 1.4: 2023-01-25
  Changes: Database references, Derived calculations
• Version 1.5: 2024-11-13
  Changes: Data collection, Structure summary
