Structure of TM1_TM2 in LPPG micelles

Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 30
  • Conformers Submitted: 20
  • Selection Criteria: structures with the lowest energy

wwPDB Validation   3D Report Full Report

This is version 1.6 of the entry. See complete history


Structure of a double transmembrane fragment of a G-protein-coupled receptor in micelles.

Neumoin, A.Cohen, L.S.Arshava, B.Tantry, S.Becker, J.M.Zerbe, O.Naider, F.

(2009) Biophys J 96: 3187-3196

  • DOI: https://doi.org/10.1016/j.bpj.2009.01.012
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    The structure and dynamic properties of an 80-residue fragment of Ste2p, the G-protein-coupled receptor for alpha-factor of Saccharomyces cerevisiae, was studied in LPPG micelles with the use of solution NMR spectroscopy. The fragment Ste2p(G31-T110) (TM1-TM2) consisted of 19 residues from the N-terminal domain, the first TM helix (TM1), the first cytoplasmic loop, the second TM helix (TM2), and seven residues from the first extracellular loop. Multidimensional NMR experiments on [(15)N], [(15)N, (13)C], [(15)N, (13)C, (2)H]-labeled TM1-TM2 and on protein fragments selectively labeled at specific amino acid residues or protonated at selected methyl groups resulted in >95% assignment of backbone and side-chain nuclei. The NMR investigation revealed the secondary structure of specific residues of TM1-TM2. TALOS constraints and NOE connectivities were used to calculate a structure for TM1-TM2 that was highlighted by the presence of three alpha-helices encompassing residues 39-47, 49-72, and 80-103, with higher flexibility around the internal Arg(58) site of TM1. RMSD values of individually superimposed helical segments 39-47, 49-72, and 80-103 were 0.25 +/- 0.10 A, 0.40 +/- 0.13 A, and 0.57 +/- 0.19 A, respectively. Several long-range interhelical connectivities supported the folding of TM1-TM2 into a tertiary structure typified by a crossed helix that splays apart toward the extracellular regions and contains considerable flexibility in the G(56)VRSG(60) region. (15)N-relaxation and hydrogen-deuterium exchange data support a stable fold for the TM parts of TM1-TM2, whereas the solvent-exposed segments are more flexible. The NMR structure is consistent with the results of biochemical experiments that identified the ligand-binding site within this region of the receptor.

  • Organizational Affiliation

    Institute of Organic Chemistry, University of Zurich, Zurich, Switzerland.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Pheromone alpha factor receptor80Saccharomyces cerevisiaeMutation(s): 4
Gene Names: STE2YFL026W
Membrane Entity: Yes
Find proteins for D6VTK4 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore D6VTK4
Go to UniProtKB:  D6VTK4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD6VTK4
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 30
  • Conformers Submitted: 20
  • Selection Criteria: structures with the lowest energy

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2009-05-05
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2020-02-19
    Changes: Data collection, Database references, Other
  • Version 1.3: 2020-10-21
    Changes: Source and taxonomy
  • Version 1.4: 2021-10-20
    Changes: Database references
  • Version 1.5: 2023-06-14
    Changes: Database references, Other
  • Version 1.6: 2024-05-08
    Changes: Data collection, Database references
