2I5F

Crystal structure of the C-terminal PH domain of pleckstrin in complex with D-myo-Ins(1,2,3,5,6)P5


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.35 Å
  • R-Value Free: 0.208
  • R-Value Work: 0.179

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Structural analysis of the carboxy terminal PH domain of pleckstrin bound to D-myo-inositol 1,2,3,5,6-pentakisphosphate.

Jackson, S.G.Zhang, Y.Haslam, R.J.Junop, M.S.

(2007) Bmc Struct.Biol. 7: 80-80

  • DOI: 10.1186/1472-6807-7-80
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Pleckstrin homology (PH) domains are one of the most prevalent domains in the human proteome and represent the major phosphoinositide-binding module. These domains are often found in signaling proteins and function predominately by targeting their ho ...

    Pleckstrin homology (PH) domains are one of the most prevalent domains in the human proteome and represent the major phosphoinositide-binding module. These domains are often found in signaling proteins and function predominately by targeting their host proteins to the cell membrane. Inositol phosphates, which are structurally similar to phosphoinositides, are not only known to play a role as signaling molecules but are also capable of being bound by PH domains.


    Organizational Affiliation

    Department of Biochemistry and Biomedical Sciences, McMaster University, Hamilton, Canada. jacksosg@mcmaster.ca




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Pleckstrin
A
109Homo sapiensMutation(s): 0
Gene Names: PLEK (P47)
Find proteins for P08567 (Homo sapiens)
Go to Gene View: PLEK
Go to UniProtKB:  P08567
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
5IP
Query on 5IP

Download SDF File
Download CCD File
A
(1R,2R,3R,4R,5S,6S)-6-HYDROXYCYCLOHEXANE-1,2,3,4,5-PENTAYL PENTAKIS[DIHYDROGEN (PHOSPHATE)]
D-MYO-INS(1,2,3,5,6)P5
C6 H17 O21 P5
CTPQAXVNYGZUAJ-RTWKJESVSA-N
 Ligand Interaction
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
5IPIC50: 2200 nM BINDINGMOAD
5IPIC50: 7500 nM PDBBIND
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.35 Å
  • R-Value Free: 0.208
  • R-Value Work: 0.179
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 32.150α = 90.00
b = 47.700β = 90.00
c = 64.060γ = 90.00
Software Package:
Software NamePurpose
CBASSdata collection
d*TREKdata scaling
d*TREKdata reduction
MOLREPphasing
REFMACrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2007-08-07
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
