2HXF

KIF1A head-microtubule complex structure in amppnp-form


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 10 Å
  • Aggregation State: FILAMENT
  • Reconstruction Method: HELICAL

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

High-resolution cryo-EM maps show the nucleotide binding pocket of KIF1A in open and closed conformations

Kikkawa, M.Hirokawa, N.

(2006) Embo J. 25: 4187-4194

  • DOI: 10.1038/sj.emboj.7601299
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Kinesin is an ATP-driven microtubule (MT)-based motor fundamental to organelle transport. Although a number of kinesin crystal structures have been solved, the structural evidence for coupling between the bound nucleotide and the conformation of kine ...

    Kinesin is an ATP-driven microtubule (MT)-based motor fundamental to organelle transport. Although a number of kinesin crystal structures have been solved, the structural evidence for coupling between the bound nucleotide and the conformation of kinesin is elusive. In addition, the structural basis of the MT-induced ATPase activity of kinesin is not clear because of the absence of the MT in the structure. Here, we report cryo-electron microscopy structures of the monomeric kinesin KIF1A-MT complex in two nucleotide states at about 10 A resolution, sufficient to reveal the secondary structure. These high-resolution maps visualized clear structural changes that suggest a mechanical pathway from the nucleotide to the neck linker via the motor core rotation. In addition, new nucleotide binding pocket conformations are observed that are different from X-ray crystallographic structures; it is closed in the 5'-adenylyl-imidodiphosphate state, but open in the ADP state. These results suggest a structural model of biased diffusion movement of monomeric kinesin motor.


    Organizational Affiliation

    Department of Cell Biology, Southwestern Medical Center, University of Texas, Dallas, TX, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Tubulin alpha chain
A
451Sus scrofaMutation(s): 0
Gene Names: TUBA1A
Find proteins for P02550 (Sus scrofa)
Go to Gene View: TUBA1A
Go to UniProtKB:  P02550
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Tubulin beta chain
B
445Sus scrofaMutation(s): 0
Find proteins for P02554 (Sus scrofa)
Go to UniProtKB:  P02554
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
Kinesin-like protein KIF1A
C
394Mus musculusMutation(s): 1
Gene Names: Kif1a (Atsv, Kif1)
Find proteins for P33173 (Mus musculus)
Go to UniProtKB:  P33173
Small Molecules
Ligands 5 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
GDP
Query on GDP

Download SDF File
Download CCD File
B
GUANOSINE-5'-DIPHOSPHATE
C10 H15 N5 O11 P2
QGWNDRXFNXRZMB-UUOKFMHZSA-N
 Ligand Interaction
GTP
Query on GTP

Download SDF File
Download CCD File
A
GUANOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O14 P3
XKMLYUALXHKNFT-UUOKFMHZSA-N
 Ligand Interaction
ANP
Query on ANP

Download SDF File
Download CCD File
C
PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER
C10 H17 N6 O12 P3
PVKSNHVPLWYQGJ-KQYNXXCUSA-N
 Ligand Interaction
MG
Query on MG

Download SDF File
Download CCD File
A, C
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
TA1
Query on TA1

Download SDF File
Download CCD File
B
TAXOL
C47 H51 N O14
RCINICONZNJXQF-MZXODVADSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 10 Å
  • Aggregation State: FILAMENT
  • Reconstruction Method: HELICAL

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2006-10-10
    Type: Initial release
  • Version 1.1: 2008-05-01
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
