2GRR

Crystal Structure of human RanGAP1-Ubc9-D127S


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.3 Å
  • R-Value Free: 0.222
  • R-Value Work: 0.201

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

Lysine activation and functional analysis of E2-mediated conjugation in the SUMO pathway.

Yunus, A.A.Lima, C.D.

(2006) Nat.Struct.Mol.Biol. 13: 491-499

  • DOI: 10.1038/nsmb1104
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • E2 conjugating proteins that transfer ubiquitin and ubiquitin-like modifiers to substrate lysine residues must first activate the lysine nucleophile for conjugation. Genetic complementation revealed three side chains of the E2 Ubc9 that were crucial ...

    E2 conjugating proteins that transfer ubiquitin and ubiquitin-like modifiers to substrate lysine residues must first activate the lysine nucleophile for conjugation. Genetic complementation revealed three side chains of the E2 Ubc9 that were crucial for normal growth. Kinetic analysis revealed modest binding defects but substantially lowered catalytic rates for these mutant alleles with respect to wild-type Ubc9. X-ray structures for wild-type and mutant human Ubc9-RanGAP1 complexes showed partial loss of contacts to the substrate lysine in mutant complexes. Computational analysis predicted pK perturbations for the substrate lysine, and Ubc9 mutations weakened pK suppression through improper side chain coordination. Biochemical studies with p53, RanGAP1 and the Nup358/RanBP2 E3 were used to determine rate constants and pK values, confirming both structural and computational predictions. It seems that Ubc9 uses an indirect mechanism to activate lysine for conjugation that may be conserved among E2 family members.


    Organizational Affiliation

    Structural Biology Program, Sloan-Kettering Institute, New York, New York 10021, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Ubiquitin-conjugating enzyme E2 I
A
161Homo sapiensMutation(s): 1
Gene Names: UBE2I (UBC9, UBCE9)
EC: 2.3.2.-
Find proteins for P63279 (Homo sapiens)
Go to Gene View: UBE2I
Go to UniProtKB:  P63279
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Ran GTPase-activating protein 1
B
170Homo sapiensMutation(s): 0
Gene Names: RANGAP1 (KIAA1835, SD)
Find proteins for P46060 (Homo sapiens)
Go to Gene View: RANGAP1
Go to UniProtKB:  P46060
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.3 Å
  • R-Value Free: 0.222
  • R-Value Work: 0.201
  • Space Group: P 1
Unit Cell:
Length (Å)Angle (°)
a = 39.150α = 72.61
b = 44.675β = 71.72
c = 61.013γ = 75.35
Software Package:
Software NamePurpose
CNSphasing
ADSCdata collection
PDB_EXTRACTdata extraction
CNSrefinement
DENZOdata reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2006-05-30
    Type: Initial release
  • Version 1.1: 2008-05-01
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
  • Version 1.3: 2017-10-18
    Type: Refinement description
