Biological Assembly 1

 3D View: Structure | Electron Density

Standalone Viewers
Protein Workshop | Ligand Explorer

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 18690.48
• Atom Count: 1311
• Residue Count: 164
• Unique protein chains: 1

1L19

ENHANCED PROTEIN THERMOSTABILITY FROM DESIGNED MUTATIONS THAT INTERACT WITH ALPHA-HELIX DIPOLES

• DOI: 10.2210/pdb1L19/pdb

• Classification: HYDROLASE (O-GLYCOSYL)
• Organism(s): Enterobacteria phage T4


• Deposited: 1989-05-01 Released: 1990-01-15
• Deposition Author(s): Nicholson, H., Matthews, B.W.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.7 Å

Literature

Enhanced protein thermostability from designed mutations that interact with alpha-helix dipoles.

Nicholson, H., Becktel, W.J., Matthews, B.W.

(1988) Nature 336: 651-656

• PubMed: 3200317
• DOI: 10.1038/336651a0
• Primary Citation of Related Structures:
  1L20


• PubMed Abstract:


Two different genetically engineered amino-acid substitutions designed to interact with alpha-helix dipoles in T4 lysozyme are shown to increase the thermal stability of the protein. Crystallographic analyses of the mutant lysozyme structures suggest that the stabilization is due to electrostatic interaction and does not require precise hydrogen bonding between the substituted amino acid and the end of the alpha-helix.

---

Related Citations:

• Common Precursor of Lysozymes of Hen Egg-White and Bacteriophage T4
  Matthews, B.W.,Gruetter, M.G.,Anderson, W.F.,Remington, S.J.
  (1981) Nature 290: 334
• Hydrophobic Stabilization in T4 Lysozyme Determined Directly by Multiple Substitutions of Ile 3
  Matsumura, M.,Becktel, W.J.,Matthews, B.W.
  (1988) Nature 334: 406
• Temperature-Sensitive Mutations of Bacteriophage T4 Lysozyme Occur at Sites with Low Mobility and Low Solvent Accessibility in the Folded Protein
  Alber, T.,Dao-Pin, S.,Nye, J.A.,Muchmore, D.C.,Matthews, B.W.
  (1987) Biochemistry 26: 3754
• The Three Dimensional Structure of the Lysozyme from Bacteriophage T4
  Matthews, B.W.,Remington, S.J.
  (1974) Proc.Natl.Acad.Sci.USA 71: 4178
• Relation between Hen Egg White Lysozyme and Bacteriophage T4 Lysozyme. Evolutionary Implications
  Matthews, B.W.,Remington, S.J.,Gruetter, M.G.,Anderson, W.F.
  (1981) J.Mol.Biol. 147: 545
• High-Resolution Structure of the Temperature-Sensitive Mutant of Phage Lysozyme, Arg 96 (Right Arrow) His
  Weaver, L.H.,Gray, T.M.,Gruetter, M.G.,Anderson, D.E.,Wozniak, J.A.,Dahlquist, F.W.,Matthews, B.W.
  (1989) Biochemistry 28: 3793
• Replacements of Pro86 in Phage T4 Lysozyme Extend an Alpha-Helix But Do not Alter Protein Stability
  Alber, T.,Bell, J.A.,Dao-Pin, S.,Nicholson, H.,Cook, J.A.Wozniak S.,Matthews, B.W.
  (1988) Science 239: 631
• Contributions of Hydrogen Bonds of Thr 157 to the Thermodynamic Stability of Phage T4 Lysozyme
  Alber, T.,Dao-Pin, S.,Wilson, K.,Wozniak, J.A.,Cook, S.P.,Matthews, B.W.
  (1987) Nature 330: 41
• Crystallographic Determination of the Mode of Binding of Oligosaccharides to T4 Bacteriophage Lysozyme. Implications for the Mechanism of Catalysis
  Anderson, W.F.,Gruetter, M.G.,Remington, S.J.,Weaver, L.H.,Matthews, B.W.
  (1981) J.Mol.Biol. 147: 523
• Structure of Bacteriophage T4 Lysozyme Refined at 1.7 Angstroms Resolution
  Weaver, L.H.,Matthews, B.W.
  (1987) J.Mol.Biol. 193: 189
• Structural Studies of Mutants of the Lysozyme of Bacteriophage T4. The Temperature-Sensitive Mutant Protein Thr157 (Right Arrow) Ile
  Gruetter, M.G.,Gray, T.M.,Weaver, L.H.,Alber, T.,Wilson, K.,Matthews, B.W.
  (1987) J.Mol.Biol. 197: 315
• Structural Analysis of the Temperature-Sensitive Mutant of Bacteriophage T4 Lysozyme, Glycine 156 (Right Arrow) Aspartic Acid
  Gray, T.M.,Matthews, B.W.
  (1987) J.Biol.Chem. 262: 16858
• Crystallographic Data for Lysozyme from Bacteriophage T4
  Matthews, B.W.,Dahlquist, F.W.,Maynard, A.Y.
  (1973) J.Mol.Biol. 78: 575
• Contributions of Left-Handed Helical Residues to the Structure and Stability of Bacteriophage T4 Lysozyme
  Nicholson, H.,Soderlind, E.,Tronrud, D.E.,Matthews, B.W.
  (1989) J.Mol.Biol. 210: 181
• Comparison of the Predicted and Observed Secondary Structure of T4 Phage Lysozyme
  Matthews, B.W.
  (1975) Biochim.Biophys.Acta 405: 442
• Structural Studies of Mutants of T4 Lysozyme that Alter Hydrophobic Stabilization
  Matsumura, M.,Wozniak, J.A.,Dao-Pin, S.,Matthews, B.W.
  () TO BE PUBLISHED --: --
• Enhanced Protein Thermostability from Site-Directed Mutations that Decrease the Entropy of Unfolding
  Matthews, B.W.,Nicholson, H.,Becktel, W.J.
  (1987) Proc.Natl.Acad.Sci.USA 84: 6663
• Atomic Coordinates for T4 Phage Lysozyme
  Remington, S.J.,Teneyck, L.F.,Matthews, B.W.
  (1977) Biochem.Biophys.Res.Commun. 75: 265
• Structure of the Lysozyme from Bacteriophage T4, an Electron Density Map at 2.4 Angstroms Resolution
  Remington, S.J.,Anderson, W.F.,Owen, J.,Teneyck, L.F.,Grainger, C.T.,Matthews, B.W.
  (1978) J.Mol.Biol. 118: 81




---

Organizational Affiliation:

Institute of Molecular Biology, University of Oregon, Eugene 97403.

Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details
T4 LYSOZYME	A	164	Enterobacteria phage T4	Mutation(s): 0  Gene Names: E EC: 3.2.1.17
Find proteins for P00720 (Enterobacteria phage T4) Go to UniProtKB:  P00720

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.7 Å
• Space Group: P 3₂ 2 1

Unit Cell:

Length (Å)	Angle (°)
a = 61.100	α = 90.00
b = 61.100	β = 90.00
c = 97.000	γ = 120.00

Software Package:

Software Name	Purpose
TNT	refinement

Structure Validation

Entry History

Deposition Data

• Deposited Date: 1989-05-01
• Released Date: 1990-01-15
• Deposition Author(s): Nicholson, H., Matthews, B.W.

Revision History

• Version 1.0: 1990-01-15
  Type: Initial release
• Version 1.1: 2008-03-24
  Type: Version format compliance
• Version 1.2: 2011-07-13
  Type: Advisory, Version format compliance
• Version 1.3: 2017-11-29
  Type: Derived calculations, Other
