1IVV

Crystal structure of copper amine oxidase from Arthrobacter globiformis: Early intermediate in topaquinone biogenesis


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.263
  • R-Value Work: 0.190
  • R-Value Observed: 0.193

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

X-ray snapshots of quinone cofactor biogenesis in bacterial copper amine oxidase.

Kim, M.Okajima, T.Kishishita, S.Yoshimura, M.Kawamori, A.Tanizawa, K.Yamaguchi, H.

(2002) Nat Struct Biol 9: 591-596

  • DOI: 10.1038/nsb824
  • Primary Citation of Related Structures:
    1IVU, 1IVV, 1IVW, 1IVX

  • PubMed Abstract:
  • The quinone cofactor TPQ in copper amine oxidase is generated by posttranslational modification of an active site tyrosine residue. Using X-ray crystallography, we have probed the copper-dependent autooxidation process of TPQ in the enzyme from Arthrobacter globiformis ...

    The quinone cofactor TPQ in copper amine oxidase is generated by posttranslational modification of an active site tyrosine residue. Using X-ray crystallography, we have probed the copper-dependent autooxidation process of TPQ in the enzyme from Arthrobacter globiformis. Apo enzyme crystals were anaerobically soaked with copper; the structure determined from this crystal provides a view of the initial state: the unmodified tyrosine coordinated to the bound copper. Exposure of the copper-bound crystals to oxygen led to the formation of freeze-trapped intermediates; structural analyses indicate that these intermediates contain dihydroxyphenylalanine quinone and trihydroxyphenylalanine. These are the first visualized intermediates during TPQ biogenesis in copper amine oxidase.


    Organizational Affiliation

    School of Science and Technology, Kwansei Gakuin University, Sanda, Hyogo 669-1337, Japan.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
amine oxidaseA, B638Arthrobacter globiformisMutation(s): 0
EC: 1.4.3.6 (PDB Primary Data), 1.4.3.21 (UniProt)
UniProt
Find proteins for P46881 (Arthrobacter globiformis)
Explore P46881
Go to UniProtKB:  P46881
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP46881
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CU
Query on CU

Download Ideal Coordinates CCD File
C [auth A],
D [auth B]
COPPER (II) ION
Cu
JPVYNHNXODAKFH-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
DAH
Query on DAH
A, B L-PEPTIDE LINKINGC9 H11 N O4PHE
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.263
  • R-Value Work: 0.190
  • R-Value Observed: 0.193
  • Space Group: I 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 157.802α = 90
b = 63.069β = 111.64
c = 183.461γ = 90
Software Package:
Software NamePurpose
MOSFLMdata reduction
SCALAdata scaling
X-PLORmodel building
X-PLORrefinement
CCP4data scaling
X-PLORphasing

Structure Validation

View Full Validation Report




Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2002-08-07
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2011-08-31
    Changes: Non-polymer description
  • Version 1.4: 2019-10-23
    Changes: Data collection, Database references, Derived calculations
