1UQ5

RICIN A-CHAIN (RECOMBINANT) N122A MUTANT


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.4 Å
  • R-Value Free: 0.214
  • R-Value Work: 0.177

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

The Effect of Mutations Surrounding and within the Active Site on the Catalytic Activity of Ricin a Chain

Marsden, C.J.Fulop, V.Day, P.Lord, J.M.

(2004) Eur.J.Biochem. 271: 153

  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Models for the binding of the sarcin-ricin loop (SRL) of 28S ribosomal RNA to ricin A chain (RTA) suggest that several surface exposed arginine residues surrounding the active site cleft make important interactions with the RNA substrate. The data pr ...

    Models for the binding of the sarcin-ricin loop (SRL) of 28S ribosomal RNA to ricin A chain (RTA) suggest that several surface exposed arginine residues surrounding the active site cleft make important interactions with the RNA substrate. The data presented in this study suggest differing roles for these arginyl residues. Substitution of Arg48 or Arg213 with Ala lowered the activity of RTA 10-fold. Furthermore, substitution of Arg213 with Asp lowered the activity of RTA 100-fold. The crystal structure of this RTA variant showed it to have an unaltered tertiary structure, suggesting that the positively charged state of Arg213 is crucial for activity. Substitution of Arg258 with Ala had no effect on activity, although substitution with Asp lowered activity 10-fold. Substitution of Arg134 prevented expression of folded protein, suggesting a structural role for this residue. Several models have been proposed for the binding of the SRL to the active site of RTA in which the principal difference lies in the conformation of the second 'G' in the target GAGA motif in the 28S rRNA substrate. In one model, the sidechain of Asn122 is proposed to make interactions with this G, whereas another model proposes interactions with Asp75 and Asn78. Site-directed mutagenesis of these residues of RTA favours the first of these models, as substitution of Asn78 with Ser yielded an RTA variant whose activity was essentially wild-type, whereas substitution of Asn122 reduced activity 37.5-fold. Substitution of Asp75 failed to yield significant folded protein, suggesting a structural role for this residue.


    Related Citations:
    • X-Ray Structure of Recombinant Ricin A-Chain at 1.8 A Resolution
      Weston, S.A.,Tucker, A.D.,Thatcher, D.R.,Derbyshire, D.J.,Pauptit, R.A.
      (1994) J.Mol.Biol. 244: 410


    Organizational Affiliation

    Department of Biological Sciences, University of Warwick, Coventry, UK.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
RICIN
A
263Ricinus communisMutation(s): 1
Find proteins for P02879 (Ricinus communis)
Go to UniProtKB:  P02879
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
ACT
Query on ACT

Download SDF File
Download CCD File
A
ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.4 Å
  • R-Value Free: 0.214
  • R-Value Work: 0.177
  • Space Group: P 41 21 2
Unit Cell:
Length (Å)Angle (°)
a = 67.500α = 90.00
b = 67.500β = 90.00
c = 140.600γ = 90.00
Software Package:
Software NamePurpose
SCALEPACKdata scaling
REFMACrefinement
CCP4phasing
DENZOdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2004-01-02
    Type: Initial release
  • Version 1.1: 2011-05-08
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
  • Version 1.3: 2018-01-17
    Type: Data collection
