Crystal structure of the vdr ligand binding domain complexed to TX522

Experimental Data Snapshot

  • Resolution: 1.90 Å
  • R-Value Free: 0.218
  • R-Value Work: 0.191
  • R-Value Observed: 0.191

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 2.1 of the entry. See complete history


Superagonistic Action of 14-epi-Analogs of 1,25-Dihydroxyvitamin D Explained by Vitamin D Receptor-Coactivator Interaction

Eelen, G.Verlinden, L.Rochel, N.Claessens, F.De Clercq, P.Vandewalle, M.Tocchini-Valentini, G.Moras, D.Bouillon, R.Verstuyf, A.

(2005) Mol Pharmacol 67: 1566-1573

  • DOI: https://doi.org/10.1124/mol.104.008730
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Two 14-epi-analogs of 1,25-dihydroxyvitamin D3 [1,25-(OH)(2)D(3)], 19-nor-14-epi-23-yne-1,25-(OH)2D3 (TX522) and 19-nor-14,20-bisepi-23-yne-1,25-(OH)2D3 (TX527), show enhanced antiproliferative (at least 10-fold) and markedly lower calcemic effects both in vitro and in vivo, compared with 1,25-(OH)2D3. This study aimed to evaluate their superagonistic effect at the level of interaction between the Vitamin D receptor (VDR) and coactivators. Mammalian two-hybrid assays with VP16-fused VDR and GAL4-DNA-binding-domain-fused steroid receptor coactivator 1 (SRC-1), transcriptional intermediary factor 2 (Tif2), or DRIP205 showed the 14-epi-analogs to be more potent inducers of VDR-coactivator interactions than 1,25-(OH)2D3 (up to 16- and 20-fold stronger induction of VDR-SRC-1 interaction for TX522 and TX527 at 10(-10) M). Similar assays in which metabolism of 1,25-(OH)2D3 was blocked with VID400, a selective inhibitor of the 1,25-(OH)2D3-metabolizing enzyme CYP24, showed that the enhanced potency of these analogs in establishing VDR-coactivator interactions can only partially be accounted for by their increased resistance to metabolic degradation. Crystallization of TX522 complexed to the ligand binding domain of the human VDR demonstrated that the epi-configuration of C14 caused the CD ring of the ligand to shift by 0.5 angstroms, thereby bringing the C12 atom into closer contact with Val300. Moreover, C22 of TX522 made an additional contact with the CD1 atom of Ile268 because of the rigidity of the triple bond-containing side chain. The position and conformation of the activation helix H12 of VDR was strictly maintained. In conclusion, this study provides deeper insight into the docking of TX522 in the LBP and shows that stronger VDR-coactivator interactions underlie the superagonistic activity of the two 14-epi-analogs.

  • Organizational Affiliation

    Laboratorium voor Experimentele Geneeskunde en Endocrinologie, Katholieke Universiteit Leuven, Belgium.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Vitamin D receptor263Homo sapiensMutation(s): 0
Gene Names: NR1I1
UniProt & NIH Common Fund Data Resources
Find proteins for P11473 (Homo sapiens)
Explore P11473
Go to UniProtKB:  P11473
PHAROS:  P11473
GTEx:  ENSG00000111424
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP11473
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on TX5

Download Ideal Coordinates CCD File
C26 H40 O3
Experimental Data & Validation

Experimental Data

  • Resolution: 1.90 Å
  • R-Value Free: 0.218
  • R-Value Work: 0.191
  • R-Value Observed: 0.191
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 45.259α = 90
b = 52.504β = 90
c = 132.93γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2005-05-10
    Type: Initial release
  • Version 1.1: 2008-04-30
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2017-08-16
    Changes: Advisory, Refinement description, Source and taxonomy
  • Version 2.0: 2020-11-04
    Changes: Advisory, Database references, Derived calculations, Non-polymer description, Structure summary
  • Version 2.1: 2024-03-13
    Changes: Advisory, Data collection, Database references
