1P5Y

The structures of host range controlling regions of the capsids of canine and feline parvoviruses and mutants


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.2 Å
  • R-Value Free: 0.253
  • R-Value Work: 0.252

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Structures of host range-controlling regions of the capsids of canine and feline parvoviruses and mutants.

Govindasamy, L.Hueffer, K.Parrish, C.R.Agbandje-McKenna, M.

(2003) J.Virol. 77: 12211-12221

  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Canine parvovirus (CPV) and feline panleukopenia virus (FPV) differ in their ability to infect dogs and dog cells. Canine cell infection is a specific property of CPV and depends on the ability of the virus to bind the canine transferrin receptor (Tf ...

    Canine parvovirus (CPV) and feline panleukopenia virus (FPV) differ in their ability to infect dogs and dog cells. Canine cell infection is a specific property of CPV and depends on the ability of the virus to bind the canine transferrin receptor (TfR), as well as other unidentified factors. Three regions in the capsid structure, located around VP2 residues 93, 300, and 323, can all influence canine TfR binding and canine cell infection. These regions were compared in the CPV and FPV capsid structures that have been determined, as well as in two new structures of CPV capsids that contain substitutions of the VP2 Asn-93 to Asp and Arg, respectively. The new structures, determined by X-ray crystallography to 3.2 and 3.3 A resolutions, respectively, clearly showed differences in the interactions of residue 93 with an adjacent loop on the capsid surface. Each of the three regions show small differences in structure, but each appears to be structurally independent of the others, and the changes likely act together to affect the ability of the capsid to bind the canine TfR and to infect canine cells. This emphasizes the complex nature of capsid alterations that change the virus-cell interaction to allow infection of cells from different hosts.


    Related Citations:
    • The three-dimensional structure of canine parvovirus and its functional implications
      Tsao, J.,Chapman, M.S.,Agbandje, M.,Keller, W.,Smith, K.,Wu, H.,Luo, M.,Smith, T.J.,Rossmann, M.G.,Compans, R.W.,Parrish, C.R.
      (1991) Science 251: 1456
    • The canine parvovirus empty capsid structure
      Wu, H.,Rossmann, M.G.
      (1993) J.Mol.Biol. 233: 231
    • Structure determination of monoclinic canine parvovirus
      Tsao, J.,Chapman, M.S.,Wu, H.,Agbandje, M.,Keller, W.,Rossmann, M.G.
      (1992) Acta Crystallogr.,Sect.B 48: 75


    Organizational Affiliation

    Department of Biochemistry and Molecular Biology, Center for Structural Biology, College of Medicine, University of Florida, Gainesville, Florida 32610, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Coat protein VP2
A
548Canine parvovirustype 2Mutations: D57N
Find proteins for P17455 (Canine parvovirustype 2)
Go to UniProtKB:  P17455
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.2 Å
  • R-Value Free: 0.253
  • R-Value Work: 0.252
  • Space Group: C 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 440.450α = 90.00
b = 246.810β = 93.54
c = 443.650γ = 90.00
Software Package:
Software NamePurpose
AMoREphasing
DENZOdata reduction
SCALEPACKdata scaling
CNSrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2003-08-26
    Type: Initial release
  • Version 1.1: 2008-04-29
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
