1P13

Crystal Structure of the Src SH2 Domain Complexed with Peptide (SDpYANFK)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.63 Å
  • R-Value Free: 0.252
  • R-Value Work: 0.207

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

The structure of the membrane distal phosphatase domain of RPTPalpha reveals interdomain flexibility and an SH2 domain interaction region.

Sonnenburg, E.D.Bilwes, A.Hunter, T.Noel, J.P.

(2003) Biochemistry 42: 7904-7914

  • DOI: 10.1021/bi0340503
  • Primary Citation of Related Structures:  1P15

  • PubMed Abstract:
  • The receptor protein tyrosine phosphatase alpha (RPTPalpha) is a transmembrane receptor with two intracellular protein tyrosine phosphatase domains, a catalytically active membrane proximal domain (D1) and a membrane distal phosphatase domain with mi ...

    The receptor protein tyrosine phosphatase alpha (RPTPalpha) is a transmembrane receptor with two intracellular protein tyrosine phosphatase domains, a catalytically active membrane proximal domain (D1) and a membrane distal phosphatase domain with minimal catalytic activity (D2). Here we elucidate the crystal structure of RPTPalpha's D2 domain. Unlike D1, D2 exists as a monomer and lacks the N-terminal inhibitory wedge motif. The N-terminal portion of D2 is disordered, and this region linking D1 to D2 is proteolytically labile in solution whether part of D2 alone or tethered to D1, indicating that the polypeptide backbone of this part of D2 is highly flexible, and therefore accessible to proteases under native conditions. Furthermore, we have crystallized the SH2 domain of the protein tyrosine kinase c-Src, a RPTPalpha substrate, with a phosphopeptide encompassing the C-terminal phosphorylation site of D2 (pTyr789). The SH2 domain of Src binds RPTPalpha in an extended conformation. The structural and functional data support a D1-D2 arrangement with significant flexibility between phosphatase domains of RPTPalpha that is likely to be important for dynamic alterations in intra- and/or intermolecular interactions that are critical for RPTPalpha function.


    Organizational Affiliation

    Structural Biology Laboratory, The Salk Institute for Biological Studies, 10010 North Torrey Pines Road, La Jolla, California 92037, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Proto-oncogene tyrosine-protein kinase Src
A, B
102Gallus gallusGene Names: SRC
EC: 2.7.10.2
Find proteins for P00523 (Gallus gallus)
Go to Gene View: SRC
Go to UniProtKB:  P00523
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Peptide
C, D
7N/AN/A
Protein Feature View is not available: No corresponding UniProt sequence found.
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CAC
Query on CAC

Download SDF File
Download CCD File
A, B
CACODYLATE ION
dimethylarsinate
C2 H6 As O2
OGGXGZAMXPVRFZ-UHFFFAOYSA-M
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
PTR
Query on PTR
C, D
L-PEPTIDE LINKINGC9 H12 N O6 PTYR
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
PTRΔG: -21.4 kJ/mol (100) BINDINGDB
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.63 Å
  • R-Value Free: 0.252
  • R-Value Work: 0.207
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 58.384α = 90.00
b = 58.793β = 90.00
c = 62.662γ = 90.00
Software Package:
Software NamePurpose
CNSrefinement
SCALEPACKdata scaling
EPMRphasing
DENZOdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2003-08-19
    Type: Initial release
  • Version 1.1: 2008-04-29
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Non-polymer description, Version format compliance
