1O7L

Molybdate-activated form of ModE from Escherichia coli


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.75 Å
  • R-Value Free: 0.254
  • R-Value Work: 0.207

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Crystal Structure of Activated Mode Reveals Conformational Changes Involving Both Oxyanion and DNA-Binding Domains

Schuttelkopf, A.W.Boxer, D.H.Hunter, W.N.

(2003) J.Mol.Biol. 326: 761


  • PubMed Abstract:
  • ModE is a bacterial transcriptional regulator that orchestrates many aspects of molybdenum metabolism by binding to specific DNA sequences in a molybdate-dependent fashion. We present the crystal structure of Escherichia coli ModE in complex with mol ...

    ModE is a bacterial transcriptional regulator that orchestrates many aspects of molybdenum metabolism by binding to specific DNA sequences in a molybdate-dependent fashion. We present the crystal structure of Escherichia coli ModE in complex with molybdate, which was determined at 2.75A from a merohedrally twinned crystal (twin fraction approximately 0.30) with space group P4(3). We now have structures of ModE in both its "switched on" (ligand-bound) and "switched off" (apo) states. Comparison with the apo structure shows that ligand binding leads to extensive conformational changes not only in the molybdate-binding domain, but also in the DNA-binding domain. The most obvious difference is the loss of the pronounced asymmetry between the two chains of the ModE dimer, which had been a characteristic property of the apo structure. Another major change concerns the relative orientation of the two DNA-interacting winged helix-turn-helix motifs. Manual docking of an idealized DNA structure suggests that this conformational change should improve DNA binding of the activated molybdate-bound ModE.


    Organizational Affiliation

    Division of Biological Chemistry and Molecular Microbiology, The Wellcome Trust Biocentre, School of Life Sciences, University of Dundee, Dundee DD1 5EH, UK.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
TRANSCRIPTIONAL REGULATOR MODE
A, B, C, D
262Escherichia coli (strain K12)Gene Names: modE (modR)
Find proteins for P0A9G8 (Escherichia coli (strain K12))
Go to UniProtKB:  P0A9G8
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
MOO
Query on MOO

Download SDF File
Download CCD File
A, B, C, D
MOLYBDATE ION
MOLYBDATE
Mo O4
MEFBJEMVZONFCJ-UHFFFAOYSA-N
 Ligand Interaction
CL
Query on CL

Download SDF File
Download CCD File
B
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
 Ligand Interaction
CA
Query on CA

Download SDF File
Download CCD File
D
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.75 Å
  • R-Value Free: 0.254
  • R-Value Work: 0.207
  • Space Group: P 43
Unit Cell:
Length (Å)Angle (°)
a = 78.831α = 90.00
b = 78.831β = 90.00
c = 195.099γ = 90.00
Software Package:
Software NamePurpose
CNSrefinement
AMoREphasing
SCALEPACKdata scaling
DENZOdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2003-02-20
    Type: Initial release
  • Version 1.1: 2011-05-08
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
