1NZ6

Crystal Structure of Auxilin J-Domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.5 Å
  • R-Value Free: 0.268
  • R-Value Work: 0.234

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

Structure-function analysis of the auxilin J-domain reveals an extended Hsc70 interaction interface.

Jiang, J.Taylor, A.B.Prasad, K.Ishikawa-Brush, Y.Hart, P.J.Lafer, E.M.Sousa, R.

(2003) Biochemistry 42: 5748-5753

  • DOI: 10.1021/bi034270g

  • PubMed Abstract:
  • J-domains are widespread protein interaction modules involved in recruiting and stimulating the activity of Hsp70 family chaperones. We have determined the crystal structure of the J-domain of auxilin, a protein which is involved in uncoating clathri ...

    J-domains are widespread protein interaction modules involved in recruiting and stimulating the activity of Hsp70 family chaperones. We have determined the crystal structure of the J-domain of auxilin, a protein which is involved in uncoating clathrin-coated vesicles. Comparison to the known structures of J-domains from four other proteins reveals that the auxilin J-domain is the most divergent of all J-domain structures described to date. In addition to the canonical J-domain features described previously, the auxilin J-domain contains an extra N-terminal helix and a long loop inserted between helices I and II. The latter loop extends the positively charged surface which forms the Hsc70 binding site, and is shown by directed mutagenesis and surface plasmon resonance to contain side chains important for binding to Hsc70.


    Organizational Affiliation

    Department of Biochemistry, University of Texas Health Science Center, 7703 Floyd Curl Drive, San Antonio, Texas 78229-3900, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Auxilin
A, B
101Bos taurusMutation(s): 0
Gene Names: DNAJC6
EC: 3.1.3.48
Find proteins for Q27974 (Bos taurus)
Go to Gene View: DNAJC6
Go to UniProtKB:  Q27974
Small Molecules
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
MSE
Query on MSE
A, B
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.5 Å
  • R-Value Free: 0.268
  • R-Value Work: 0.234
  • Space Group: C 2 2 21
Unit Cell:
Length (Å)Angle (°)
a = 94.066α = 90.00
b = 103.138β = 90.00
c = 75.657γ = 90.00
Software Package:
Software NamePurpose
SHARPphasing
SCALEPACKdata scaling
CNSrefinement
HKL-2000data reduction
HKL-2000data collection

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2003-04-22
    Type: Initial release
  • Version 1.1: 2008-04-29
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
  • Version 1.3: 2011-11-16
    Type: Atomic model
