1MIQ

Crystal structure of proplasmepsin from the human malarial pathogen Plasmodium vivax


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.5 Å
  • R-Value Free: 0.245
  • R-Value Work: 0.203

wwPDB Validation 3D Report Full Report


This is version 1.4 of the entry. See complete history

Literature

Structural insights into the activation of P. vivax plasmepsin.

Bernstein, N.K.Cherney, M.M.Yowell, C.A.Dame, J.B.James, M.N.

(2003) J.Mol.Biol. 329: 505-524

  • Primary Citation of Related Structures:  1QS8
  • Also Cited By: 4Y7H, 4YA8, 4Z22, 5BWY, 5JOD

  • PubMed Abstract:
  • The malarial aspartic proteinases (plasmepsins) have been discovered in several species of Plasmodium, including all four of the human malarial pathogens. In P.falciparum, plasmepsins I, II, IV and HAP have been directly implicated in hemoglobin degr ...

    The malarial aspartic proteinases (plasmepsins) have been discovered in several species of Plasmodium, including all four of the human malarial pathogens. In P.falciparum, plasmepsins I, II, IV and HAP have been directly implicated in hemoglobin degradation during malaria infection, and are now considered targets for anti-malarial drug design. The plasmepsins are produced from inactive zymogens, proplasmepsins, having unusually long N-terminal prosegments of more than 120 amino acids. Structural and biochemical evidence suggests that the conversion process of proplasmepsins to plasmepsins differs substantially from the gastric and plant aspartic proteinases. Instead of blocking substrate access to a pre-formed active site, the prosegment enforces a conformation in which proplasmepsin cannot form a functional active site. We have determined crystal structures of plasmepsin and proplasmepsin from P.vivax. The three-dimensional structure of P.vivax plasmepsin is typical of the monomeric aspartic proteinases, and the structure of P.vivax proplasmepsin is similar to that of P.falciparum proplasmepsin II. A dramatic refolding of the mature N terminus and a large (18 degrees ) reorientation of the N-domain between P.vivax proplasmepsin and plasmepsin results in a severe distortion of the active site region of the zymogen relative to that of the mature enzyme. The present structures confirm that the mode of inactivation observed originally in P.falciparum proplasmepsin II, i.e. an incompletely formed active site, is a true structural feature and likely represents the general mode of inactivation of the related proplasmepsins.


    Organizational Affiliation

    CIHR Group in Protein Structure and Function, Department of Biochemistry, University of Alberta, Edmonton, Alberta, Canada T6G 2H7.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
plasmepsin
A, B
375Plasmodium vivaxN/A
Find proteins for O60989 (Plasmodium vivax)
Go to UniProtKB:  O60989
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.5 Å
  • R-Value Free: 0.245
  • R-Value Work: 0.203
  • Space Group: C 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 149.409α = 90.00
b = 92.735β = 130.11
c = 99.132γ = 90.00
Software Package:
Software NamePurpose
AMoREphasing
REFMACrefinement
DENZOdata reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2002-09-18
    Type: Initial release
  • Version 1.1: 2008-04-28
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Advisory, Version format compliance
  • Version 1.3: 2018-01-24
    Type: Data collection
  • Version 1.4: 2018-01-31
    Type: Experimental preparation
