1LOT

CRYSTAL STRUCTURE OF THE COMPLEX OF ACTIN WITH VITAMIN D-BINDING PROTEIN


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.5 Å
  • R-Value Free: 0.279
  • R-Value Work: 0.226

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Crystal structure of the complex between actin and human vitamin D-binding protein at 2.5 A resolution.

Head, J.F.Swamy, N.Ray, R.

(2002) Biochemistry 41: 9015-9020


  • PubMed Abstract:
  • A high-affinity complex formed between G-actin and plasma vitamin D-binding protein (DBP) is believed to form part of a scavenging system in the plasma for removing actin released from damaged cells. In the study presented here, we describe the cryst ...

    A high-affinity complex formed between G-actin and plasma vitamin D-binding protein (DBP) is believed to form part of a scavenging system in the plasma for removing actin released from damaged cells. In the study presented here, we describe the crystal structure of the complex between actin and human vitamin D-binding protein at 2.5 A resolution. The complex contains one molecule of each protein bound together by extensive ionic, polar, and hydrophobic interactions. It includes an ATP and a calcium ion bound to actin, but no evidence of vitamin D metabolites bound to the DBP. Both actin and DBP are multidomain molecules, two major domains in actin and three in DBP. All of these domains contribute to the interaction between the molecules. DBP enfolds the end of the actin molecule, principally in actin subdomain 3 but with additional interactions in actin subdomain 1. This orientation is similar to the binding of profilin to actin, as predicted from previous studies. The more extensive interactions of DBP give an affinity for actin some 3 orders of magnitude higher than that for profilin. The larger "footprint" of DBP on actin also leads to an overlap with the actin-binding site of gelsolin domain I.


    Organizational Affiliation

    Department of Physiology and Biophysics, Boston University School of Medicine, Boston, Massachusetts 02118, USA. head@bu.edu




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Vitamin D-binding protein
A
458Homo sapiensMutation(s): 0
Gene Names: GC
Find proteins for P02774 (Homo sapiens)
Go to Gene View: GC
Go to UniProtKB:  P02774
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Actin, alpha skeletal muscle
B
375Oryctolagus cuniculusMutation(s): 0
Gene Names: ACTA1 (ACTA)
Find proteins for P68135 (Oryctolagus cuniculus)
Go to Gene View: ACTA1
Go to UniProtKB:  P68135
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ATP
Query on ATP

Download SDF File
Download CCD File
B
ADENOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O13 P3
ZKHQWZAMYRWXGA-KQYNXXCUSA-N
 Ligand Interaction
GOL
Query on GOL

Download SDF File
Download CCD File
A, B
GLYCEROL
GLYCERIN; PROPANE-1,2,3-TRIOL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
CA
Query on CA

Download SDF File
Download CCD File
B
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
HIC
Query on HIC
B
L-PEPTIDE LINKINGC7 H11 N3 O2HIS
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.5 Å
  • R-Value Free: 0.279
  • R-Value Work: 0.226
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 80.171α = 90.00
b = 87.341β = 90.00
c = 159.584γ = 90.00
Software Package:
Software NamePurpose
HKL-2000data reduction
HKL-2000data collection
AMoREphasing
CNSrefinement
SCALEPACKdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2002-07-31
    Type: Initial release
  • Version 1.1: 2008-04-28
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Non-polymer description, Version format compliance
