1L0Y

T cell receptor beta chain complexed with superantigen SpeA soaked with zinc


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free: 0.262
  • R-Value Work: 0.221
  • R-Value Observed: 0.221

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Structures of two streptococcal superantigens bound to TCR beta chains reveal diversity in the architecture of T cell signaling complexes.

Sundberg, E.J.Li, H.Llera, A.S.McCormick, J.K.Tormo, J.Schlievert, P.M.Karjalainen, K.Mariuzza, R.A.

(2002) Structure 10: 687-699

  • DOI: 10.1016/s0969-2126(02)00759-1
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • Superantigens (SAGs) crosslink MHC class II and TCR molecules, resulting in an overstimulation of T cells associated with human disease. SAGs interact with several different surfaces on MHC molecules, necessitating the formation of multiple distinct ...

    Superantigens (SAGs) crosslink MHC class II and TCR molecules, resulting in an overstimulation of T cells associated with human disease. SAGs interact with several different surfaces on MHC molecules, necessitating the formation of multiple distinct MHC-SAG-TCR ternary signaling complexes. Variability in SAG-TCR binding modes could also contribute to the structural heterogeneity of SAG-dependent signaling complexes. We report crystal structures of the streptococcal SAGs SpeA and SpeC in complex with their corresponding TCR beta chain ligands that reveal distinct TCR binding modes. The SpeC-TCR beta chain complex structure, coupled with the recently determined SpeC-HLA-DR2a complex structure, provides a model for a novel T cell signaling complex that precludes direct TCR-MHC interactions. Thus, highly efficient T cell activation may be achieved through structurally diverse strategies of TCR ligation.


    Organizational Affiliation

    Center for Advanced Research in Biotechnology, W.M. Keck Laboratory for Structural Biology, University of Maryland Biotechnology Institute, 9600 Gudelsky Drive, Rockville, MD 20850, USA.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
14.3.d T cell receptor beta chain
A, C
236Mus musculusMutation(s): 3
Find proteins for P01851 (Mus musculus)
Go to UniProtKB:  P01851

Find similar proteins by: Sequence  |  Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Exotoxin type A
B, D
221Streptococcus pyogenesMutation(s): 1
Gene Names: speA
Find proteins for P0DJY7 (Streptococcus pyogenes)
Go to UniProtKB:  P0DJY7
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
GOL
Query on GOL

Download CCD File
A
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
ZN
Query on ZN

Download CCD File
A, B, C, D
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free: 0.262
  • R-Value Work: 0.221
  • R-Value Observed: 0.221
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 71.722α = 90
b = 83.734β = 91.74
c = 93.9γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
TRUNCATEdata reduction
AMoREphasing
CNSrefinement
CCP4data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2002-04-03
    Type: Initial release
  • Version 1.1: 2008-04-28
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Non-polymer description, Version format compliance
  • Version 1.3: 2013-09-25
    Changes: Derived calculations
