1HUF

CRYSTAL STRUCTURE OF THE N-TERMINAL DOMAIN OF THE TYROSINE PHOSPHATASE YOPH FROM YERSINIA PESTIS.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2 Å
  • R-Value Free: 0.260
  • R-Value Work: 0.189

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Structure of the N-terminal domain of Yersinia pestis YopH at 2.0 A resolution.

Evdokimov, A.G.Tropea, J.E.Routzahn, K.M.Copeland, T.D.Waugh, D.S.

(2001) Acta Crystallogr.,Sect.D 57: 793-799


  • PubMed Abstract:
  • Yersinia pestis, the causative agent of bubonic plague, injects effector proteins into the cytosol of mammalian cells that enable the bacterium to evade the immune response of the infected organism by interfering with eukaryotic signal transduction p ...

    Yersinia pestis, the causative agent of bubonic plague, injects effector proteins into the cytosol of mammalian cells that enable the bacterium to evade the immune response of the infected organism by interfering with eukaryotic signal transduction pathways. YopH is a modular effector composed of a C-terminal protein tyrosine phosphatase (PTPase) domain and a multifunctional N-terminal domain that not only orchestrates the secretion and translocation of YopH into eukaryotic cells but also binds tyrosine-phosphorylated target proteins to mediate substrate recognition. The crystal structure of the N-terminal domain of YopH (YopH(N); residues 1-130) has been determined at 2.0 A resolution. The amino-acid sequences that target YopH for secretion from the bacterium and translocation into eukaryotic cells form integral parts of this compactly folded domain. The structure of YopH(N) bears no resemblance to eukaryotic phosphotyrosine-binding domains, nor is it reminiscent of any known fold. Residues that have been implicated in phosphotyrosine-dependent protein binding are clustered together on one face of YopH(N), but the structure does not suggest a mechanism for protein-phosphotyrosine recognition.


    Organizational Affiliation

    Protein Engineering Section, Macromolecular Crystallography Laboratory, National Cancer Institute at Frederick, PO Box B, Frederick, MD 21702-1201, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
TYROSINE PHOSPHATASE YOPH
A
140Yersinia pestisGene Names: yopH, yopH
Find proteins for O68720 (Yersinia pestis)
Go to UniProtKB:  O68720
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2 Å
  • R-Value Free: 0.260
  • R-Value Work: 0.189
  • Space Group: C 2 2 21
Unit Cell:
Length (Å)Angle (°)
a = 48.063α = 90.00
b = 120.651β = 90.00
c = 49.036γ = 90.00
Software Package:
Software NamePurpose
DENZOdata reduction
SHELXL-97refinement
SOLVEphasing
CNSrefinement
SCALEPACKdata scaling
CNSphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2001-05-23
    Type: Initial release
  • Version 1.1: 2008-04-27
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
