1GZH

Crystal structure of the BRCT domains of human 53BP1 bound to the p53 tumor supressor

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.288
  • R-Value Work: 0.238
  • R-Value Observed: 0.238

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history.


Literature

Crystal Structure of Human 53BP1 Brct Domains Bound to P53 Tumour Suppressor

Derbyshire, D.J., Basu, B.P., Serpell, L., Joo, W., Date, T., Iwabuchi, K., Doherty, A.J.

(2002) EMBO J 21: 3863

  • DOI: 10.1093/emboj/cdf383
  • Primary Citation of Related Structures:
    1GZH

  • PubMed Abstract:

    • The BRCT (BRCA1 C-terminus) is an evolutionary conserved protein-protein interacting module found as single, tandem or multiple repeats in a diverse range of proteins known to play roles in the DNA-damage response. The BRCT domains of 53BP1 bind to the tumour suppressor p53 ...

    The BRCT (BRCA1 C-terminus) is an evolutionary conserved protein-protein interacting module found as single, tandem or multiple repeats in a diverse range of proteins known to play roles in the DNA-damage response. The BRCT domains of 53BP1 bind to the tumour suppressor p53. To investigate the nature of this interaction, we have determined the crystal structure of the 53BP1 BRCT tandem repeat in complex with the DNA-binding domain of p53. The structure of the 53BP1-p53 complex shows that the BRCT tandem repeats pack together through a conserved interface that also involves the inter-domain linker. A comparison of the structure of the BRCT region of 53BP1 with the BRCA1 BRCT tandem repeat reveals that the interdomain interface and linker regions are remarkably well conserved. 53BP1 binds to p53 through contacts with the N-terminal BRCT repeat and the inter-BRCT linker. The p53 residues involved in this binding are mutated in cancer and are also important for DNA binding. We propose that BRCT domains bind to cellular target proteins through a conserved structural element termed the 'BRCT recognition motif'.

    Related Citations:
    • Purification, Crystallization and Preliminary X-Ray Analysis of the Brct Domains of Human 53BP1 Bound to the P53 Tumour Suppressor.
      Derbyshire, D.J., Basu, B.P., Date, T., Iwabuchi, K., Doherty, A.J.
      (2002) Acta Crystallogr D Biol Crystallogr 58: 1826
    Organizational Affiliation:

    Structural Medicine Unit, Cambridge Institute for Medical Research and Department of Haematology, University of Cambridge, Hills Road, Cambridge CB2 2XY, UK.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
CELLULAR TUMOR ANTIGEN P53A198Homo sapiensMutation(s): 0
Gene Names: TP53, P53
UniProt & NIH Common Fund Data Resources
Find proteins for P04637 (Homo sapiens)
Explore P04637
Go to UniProtKB:  P04637
PHAROS:  P04637
GTEx:  ENSG00000141510
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04637
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
TUMOR SUPPRESSOR P53-BINDING PROTEIN 1B, D249Homo sapiensMutation(s): 0
Gene Names: TP53BP1
UniProt & NIH Common Fund Data Resources
Find proteins for Q12888 (Homo sapiens)
Explore Q12888
Go to UniProtKB:  Q12888
PHAROS:  Q12888
GTEx:  ENSG00000067369
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ12888
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
CELLULAR TUMOR ANTIGEN P53C198Homo sapiensMutation(s): 0
Gene Names: TP53, P53
UniProt & NIH Common Fund Data Resources
Find proteins for P04637 (Homo sapiens)
Explore P04637
Go to UniProtKB:  P04637
PHAROS:  P04637
GTEx:  ENSG00000141510
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04637
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4
Download Ideal Coordinates CCD File
F [auth B],
H [auth D]		SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L		 Ligand Interaction
ZN
Query on ZN
Download Ideal Coordinates CCD File
E [auth A],
G [auth C]		ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.288
  • R-Value Work: 0.238
  • R-Value Observed: 0.238
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 71.52α = 90
b = 94.57β = 90
c = 136.2γ = 90
Software Package:
Software NamePurpose
CNSrefinement
MOSFLMdata reduction
SCALAdata scaling
AMoREphasing

Structure Validation

View Full Validation Report



View more in-depth experimental data

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2002-06-27
    Type: Initial release
  • Version 1.1: 2014-02-05
    Changes: Database references, Derived calculations, Non-polymer description, Other, Refinement description, Structure summary, Version format compliance
