1G9I

CRYSTAL STRUCTURE OF BETA-TRYSIN COMPLEX IN CYCLOHEXANE


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.243
  • R-Value Work: 0.185
  • R-Value Observed: 0.193

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

X-Ray study on an artificial mung bean inhibitor complex with bovine beta-trypsin in neat cyclohexane.

Zhu, G.Huang, Q.Zhu, Y.Li, Y.Chi, C.Tang, Y.

(2001) Biochim Biophys Acta 1546: 98-106

  • DOI: 10.1016/s0167-4838(00)00299-5
  • Primary Citation of Related Structures:
    1G9I

  • PubMed Abstract:
  • The active trypsin inhibiting component, SPC1, was obtained during the synthesis of a 22-residue peptide with three disulfide bridges according to the mimic mung bean Bowman-Birk type inhibitor. The K(i) value of SPC1 is 1.2x10(-7) M. In order to determine the topological structure of SPC1, X-ray diffraction studies were carried out on the complex of SPC1 with bovine beta-trypsin ...

    The active trypsin inhibiting component, SPC1, was obtained during the synthesis of a 22-residue peptide with three disulfide bridges according to the mimic mung bean Bowman-Birk type inhibitor. The K(i) value of SPC1 is 1.2x10(-7) M. In order to determine the topological structure of SPC1, X-ray diffraction studies were carried out on the complex of SPC1 with bovine beta-trypsin. Only the binding loop of SPC1 resolved at 2.2 A resolution due to conformational flexibility of the other residues [1]. The amino acid sequence was re-determined and electrospray mass spectroscopy was also performed to ensure that no cleaving occurred on SPC1 and the primary sequence of SPC1 is correct. Because the protein is more rigid in nonaqueous medium as has been proved by others [2], we treated the complex of SPC1 with neat cyclohexane and then subjected it to X-ray diffraction analysis, and the result showed that all the 22 residues of SPC1 were located in the electron density map. So the topological structure of SPC1 has been determined, suggesting that crystal treatment with cyclohexane may be used as a method to determine the conformation of the disordered regions in protein crystal structures.


    Related Citations:
    • Studies on an Artificial Trypsin Inhibitor Peptide Derived from the Mung Bean Inhibitor
      Li, Y., Huang, Q., Zhang, S., Liu, S., Chi, C., Tang, Y.
      (1994) J Biochem 116: 18

    Organizational Affiliation

    Department of Chemistry, Peking University, Beijing 100871, People's Republic of China.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
TRYPSINOGEN, CATIONICA [auth E]223Bos taurusMutation(s): 0
EC: 3.4.21.4
Find proteins for P00760 (Bos taurus)
Explore P00760
Go to UniProtKB:  P00760
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
BOWMAN-BIRK TYPE TRYPSIN INHIBITORB [auth I]22N/AMutation(s): 2
Find proteins for P01062 (Vigna radiata var. radiata)
Explore P01062
Go to UniProtKB:  P01062
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download Ideal Coordinates CCD File
D [auth E], ESULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
CA
Query on CA

Download Ideal Coordinates CCD File
C [auth E]CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.243
  • R-Value Work: 0.185
  • R-Value Observed: 0.193
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 62.38α = 90
b = 63.35β = 90
c = 69.04γ = 90
Software Package:
Software NamePurpose
X-PLORmodel building
X-PLORrefinement
X-PLORphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2000-12-06
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Atomic model, Database references, Derived calculations, Non-polymer description, Structure summary, Version format compliance
  • Version 1.3: 2017-10-04
    Changes: Refinement description
