1FIY

THREE-DIMENSIONAL STRUCTURE OF PHOSPHOENOLPYRUVATE CARBOXYLASE FROM ESCHERICHIA COLI AT 2.8 A RESOLUTION


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.259
  • R-Value Observed: 0.219

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Three-dimensional structure of phosphoenolpyruvate carboxylase: a proposed mechanism for allosteric inhibition.

Kai, Y.Matsumura, H.Inoue, T.Terada, K.Nagara, Y.Yoshinaga, T.Kihara, A.Tsumura, K.Izui, K.

(1999) Proc Natl Acad Sci U S A 96: 823-828

  • DOI: 10.1073/pnas.96.3.823
  • Primary Citation of Related Structures:
    1FIY

  • PubMed Abstract:
  • The crystal structure of phosphoenolpyruvate carboxylase (PEPC; EC 4. 1.1.31) has been determined by x-ray diffraction methods at 2.8-A resolution by using Escherichia coli PEPC complexed with L-aspartate, an allosteric inhibitor of all known PEPCs. ...

    The crystal structure of phosphoenolpyruvate carboxylase (PEPC; EC 4. 1.1.31) has been determined by x-ray diffraction methods at 2.8-A resolution by using Escherichia coli PEPC complexed with L-aspartate, an allosteric inhibitor of all known PEPCs. The four subunits are arranged in a "dimer-of-dimers" form with respect to subunit contact, resulting in an overall square arrangement. The contents of alpha-helices and beta-strands are 65% and 5%, respectively. All of the eight beta-strands, which are widely dispersed in the primary structure, participate in the formation of a single beta-barrel. Replacement of a conserved Arg residue (Arg-438) in this linkage with Cys increased the tendency of the enzyme to dissociate into dimers. The location of the catalytic site is likely to be near the C-terminal side of the beta-barrel. The binding site for L-aspartate is located about 20 A away from the catalytic site, and four residues (Lys-773, Arg-832, Arg-587, and Asn-881) are involved in effector binding. The participation of Arg-587 is unexpected, because it is known to be catalytically essential. Because this residue is in a highly conserved glycine-rich loop, which is characteristic of PEPC, L-aspartate seemingly causes inhibition by removing this glycine-rich loop from the catalytic site. There is another mobile loop from Lys-702 to Gly-708 that is missing in the crystal structure. The importance of this loop in catalytic activity was also shown. Thus, the crystal-structure determination of PEPC revealed two mobile loops bearing the enzymatic functions and accompanying allosteric inhibition by L-aspartate.


    Related Citations:
    • First Crystallization of a Phosphoenolpyruvate Carboxylase from Escherichia Coli
      Inoue, M., Hayashi, M., Sugimoto, M., Harada, S., Kai, Y., Kasai, N., Terada, K., Izui, K.
      (1989) J Mol Biol 208: 509

    Organizational Affiliation

    Department of Materials Chemistry, Graduate School of Engineering, Osaka University, Suita, 565-0871, Japan. kai@chem.eng.osaka-u.ac.jp



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
PHOSPHOENOLPYRUVATE CARBOXYLASEA883Escherichia coli K-12Mutation(s): 0
Gene Names: ppcglub3956JW3928
EC: 4.1.1.31
Find proteins for P00864 (Escherichia coli (strain K12))
Explore P00864
Go to UniProtKB:  P00864
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ASP
Query on ASP

Download Ideal Coordinates CCD File
A
ASPARTIC ACID
C4 H7 N O4
CKLJMWTZIZZHCS-REOHCLBHSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.259
  • R-Value Observed: 0.219
  • Space Group: I 2 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 117.6α = 90
b = 248.4β = 90
c = 82.7γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
DMmodel building
MLPHAREphasing
REFMACrefinement
DMphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 1999-02-09
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Source and taxonomy, Version format compliance
  • Version 1.3: 2018-05-23
    Changes: Data collection, Derived calculations
