Experimental Data Snapshot

  • Resolution: 1.90 Å
  • R-Value Free: 0.249
  • R-Value Work: 0.189
  • R-Value Observed: 0.189

wwPDB Validation   3D Report Full Report

This is version 1.5 of the entry. See complete history


Contribution of the hydrogen-bond network involving a tyrosine triad in the active site to the structure and function of a highly proficient ketosteroid isomerase from Pseudomonas putida biotype B.

Kim, D.H.Jang, D.S.Nam, G.H.Choi, G.Kim, J.S.Ha, N.C.Kim, M.S.Oh, B.H.Choi, K.Y.

(2000) Biochemistry 39: 4581-4589

  • DOI: https://doi.org/10.1021/bi992119u
  • Primary Citation of Related Structures:
    1DMM, 1DMN, 1DMQ

  • PubMed Abstract:

    Delta(5)-3-Ketosteroid isomerase from Pseudomonas putida biotype B is one of the most proficient enzymes catalyzing an allylic isomerization reaction at rates comparable to the diffusion limit. The hydrogen-bond network (Asp99... Wat504...Tyr14...Tyr55...Tyr30) which links the two catalytic residues, Tyr14 and Asp99, to Tyr30, Tyr55, and a water molecule in the highly apolar active site has been characterized in an effort to identify its roles in function and stability. The DeltaG(U)(H2O) determined from equilibrium unfolding experiments reveals that the elimination of the hydroxyl group of Tyr14 or Tyr55 or the replacement of Asp99 with leucine results in a loss of conformational stability of 3.5-4.4 kcal/mol, suggesting that the hydrogen bonds of Tyr14, Tyr55, and Asp99 contribute significantly to stability. While decreasing the stability by about 6.5-7.9 kcal/mol, the Y55F/D99L or Y30F/D99L double mutation also reduced activity significantly, exhibiting a synergistic effect on k(cat) relative to the respective single mutations. These results indicate that the hydrogen-bond network is important for both stability and function. Additionally, they suggest that Tyr14 cannot function efficiently alone without additional support from the hydrogen bonds of Tyr55 and Asp99. The crystal structure of Y55F as determined at 1.9 A resolution shows that Tyr14 OH undergoes an alteration in orientation to form a new hydrogen bond with Tyr30. This observation supports the role of Tyr55 OH in positioning Tyr14 properly to optimize the hydrogen bond between Tyr14 and C3-O of the steroid substrate. No significant structural changes were observed in the crystal structures of Y30F and Y30F/Y55F, which allowed us to estimate approximately the interaction energies mediated by the hydrogen bonds Tyr30...Tyr55 and Tyr14...Tyr55. Taken together, our results demonstrate that the hydrogen-bond network provides the structural support that is needed for the enzyme to maintain the active-site geometry optimized for both function and stability.

  • Organizational Affiliation

    Division of Molecular Life Sciences, Center for Biofunctional Molecules, Pohang University of Science and Technology, Pohang 790-784, South Korea.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
STEROID DELTA-ISOMERASE131Pseudomonas putidaMutation(s): 1
Find proteins for P07445 (Pseudomonas putida)
Explore P07445
Go to UniProtKB:  P07445
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP07445
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 1.90 Å
  • R-Value Free: 0.249
  • R-Value Work: 0.189
  • R-Value Observed: 0.189
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 36.09α = 90
b = 95.98β = 90
c = 74.25γ = 90
Software Package:
Software NamePurpose
X-PLORmodel building
DENZOdata reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2000-05-23
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2018-01-31
    Changes: Experimental preparation
  • Version 1.4: 2021-11-03
    Changes: Database references
  • Version 1.5: 2024-02-07
    Changes: Data collection
