1DKK

BOBWHITE QUAIL LYSOZYME WITH NITRATE


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.9 Å
  • R-Value Work: 0.157

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

Refined structures of bobwhite quail lysozyme uncomplexed and complexed with the HyHEL-5 Fab fragment.

Chacko, S.Silverton, E.W.Smith-Gill, S.J.Davies, D.R.Shick, K.A.Xavier, K.A.Willson, R.C.Jeffrey, P.D.Chang, C.Y.Sieker, L.C.Sheriff, S.

(1996) Proteins 26: 55-65

  • DOI: 10.1002/(SICI)1097-0134(199609)26:1<55::AID-PROT5>3.0.CO;2-F
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The HyHEL-5 antibody has more than a thousandfold lower affinity for bobwhite quail lysozyme (BWQL) than for hen egg-white lysozyme (HEL). Four sequence differences exist between BWQL and HEL, of which only one is involved in the interface with the F ...

    The HyHEL-5 antibody has more than a thousandfold lower affinity for bobwhite quail lysozyme (BWQL) than for hen egg-white lysozyme (HEL). Four sequence differences exist between BWQL and HEL, of which only one is involved in the interface with the Fab. The structure of bobwhite quail lysozyme has been determined in the uncomplexed state in two different crystal forms and in the complexed state with HyHEL-5, an antihen egg-white lysozyme Fab. Similar backbone conformations are observed in the three molecules of the two crystal forms of uncomplexed BWQL, although they show considerable variability in side-chain conformation. A relatively mobile segment in uncomplexed BWQL is observed to be part of the HyHEL-5 epitope. No major backbone conformational differences are observed in the lysozyme upon complex formation, but side-chain conformational differences are seen in surface residues that are involved in the interface with the antibody. The hydrogen bonding in the interface between BWQL and HyHEL-5 is similar to that in previously determined lysozyme-HyHEL-5 complexes.


    Organizational Affiliation

    Laboratory of Molecular Biology, NIDDK, NIH, Bethesda, Maryland 20895, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
LYSOZYME
A, B
129Colinus virginianusGene Names: LYZ
EC: 3.2.1.17
Find proteins for P00700 (Colinus virginianus)
Go to Gene View: LYZ
Go to UniProtKB:  P00700
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NO3
Query on NO3

Download SDF File
Download CCD File
A, B
NITRATE ION
N O3
NHNBFGGVMKEFGY-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.9 Å
  • R-Value Work: 0.157
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 28.000α = 90.00
b = 62.600β = 91.60
c = 60.800γ = 90.00
Software Package:
Software NamePurpose
X-PLORphasing
X-PLORrefinement
MADNESdata reduction
X-PLORmodel building
MADNESdata collection

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 1996-07-11
    Type: Initial release
  • Version 1.1: 2008-03-03
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
  • Version 1.3: 2018-04-18
    Type: Data collection, Other
