1BJA

ACTIVATION DOMAIN OF THE PHAGE T4 TRANSCRIPTION FACTOR MOTA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.19 Å
  • R-Value Free: 0.291
  • R-Value Work: 0.208

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

The activation domain of the MotA transcription factor from bacteriophage T4.

Finnin, M.S.Cicero, M.P.Davies, C.Porter, S.J.White, S.W.Kreuzer, K.N.

(1997) EMBO J. 16: 1992-2003

  • DOI: 10.1093/emboj/16.8.1992

  • PubMed Abstract:
  • Bacteriophage T4 encodes a transcription factor, MotA, that binds to the -30 region of middle-mode promoters and activates transcription by host RNA polymerase. We have solved the structure of the MotA activation domain to 2.2 A by X-ray crystallogra ...

    Bacteriophage T4 encodes a transcription factor, MotA, that binds to the -30 region of middle-mode promoters and activates transcription by host RNA polymerase. We have solved the structure of the MotA activation domain to 2.2 A by X-ray crystallography, and have also determined its secondary structure by NMR. An area on the surface of the protein has a distinctive patch that is populated with acidic and hydrophobic residues. Mutations within this patch cause a defective T4 growth phenotype, arguing that the patch is important for MotA function. One of the mutant MotA activation domains was purified and analyzed by NMR, and the spectra clearly show that the domain is properly folded. The mutant full-length protein appears to bind DNA normally but is deficient in transcriptional activation. We conclude that the acidic/hydrophobic surface patch is specifically involved in transcriptional activation, which is reminiscent of eukaryotic acidic activation domains.


    Organizational Affiliation

    Department of Microbiology, Duke University Medical Center, Durham, NC 27710, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
TRANSCRIPTION REGULATORY PROTEIN MOTA
A, B
95Enterobacteria phage T4Mutation(s): 0
Gene Names: motA
Find proteins for P22915 (Enterobacteria phage T4)
Go to UniProtKB:  P22915
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.19 Å
  • R-Value Free: 0.291
  • R-Value Work: 0.208
  • Space Group: P 32 2 1
Unit Cell:
Length (Å)Angle (°)
a = 46.700α = 90.00
b = 46.700β = 90.00
c = 139.600γ = 120.00
Software Package:
Software NamePurpose
SCALEPACKdata scaling
DENZOdata reduction
X-PLORmodel building
X-PLORrefinement
X-PLORphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 1998-11-04
    Type: Initial release
  • Version 1.1: 2008-03-03
    Type: Version format compliance
  • Version 1.2: 2011-07-13
    Type: Version format compliance
